Vacuum Tube LEDs: Radome Prototype

Definitely not a vacuum tube:

Arduino Pro Mini – NP-BX1 cell – SK6812 – blue phase

It’s running the same firmware, though, with the Arduino Pro Mini and the LEDs drawing power from the (mostly) defunct lithium battery.

The LED holder is identical to the Pirhana holder, with a 10 mm diameter recess punched into it for the SK6812 PCB:

Astable Multivibrator Battery Holder – Neopixel PCB – Slic3r

Those embossed legends sit in debossed rectangles for improved legibility. If I repeat it often enough, I’m sure I’ll remember which is which.

The 3.6 V (and declining) power supply may not produce as much light from the SK6812 LEDs, but it’s entirely adequate for anything other than a well-lit room. The 28 AWG silicone wires require a bit of careful dressing to emerge from the holes in the radome holder:

SK6812 LED PCB – Pirhana holder wiring

The firmware cycles through all the usual colors:

Arduino Pro Mini – NP-BX1 cell – SK6812 – orange phase

A pair of tensilized 22 AWG copper wires support the Pro Mini between the rear struts. The whole affair looks a bit heavier than I expected, though, so I should reduce the spider to a single pair of legs with a third hole in the bottom of the LED recess for the data wire.

The OpenSCAD source code needs some refactoring and tweaking, but the Pirhana LED solid model version of the battery holder should give you the general idea.

2019-01-29
Vacuum Tube LEDs: Arduino Pro Mini vs. NP-BX1 Battery

A year or so ago, a certain Young Engineer suggested my Vacuum Tube Lights really needed battery power and rebuffed my feeble objections concerning low LED intensity (3.6-ish V, not plug-in 5 V USB) and short run time (because three constantly lit LEDs draw too much current). Having a spare NP-BX1 holder lying about, here’s a feasibility study:

Arduino Pro Mini – Neopixel – NP-BX1 battery

Not much to it, eh?

Hitching the DSO150 to a Tek current probe (which needs a 50 Ω load, thus the terminator on the BNC tee) seems a clear-cut case of a sow’s ear joining forces with a silk purse:

DSO150 – Arduino Pro Mini – Neopixel current

It was just sitting there, so why not?

Seen with a bit more detail on a better scope:

Ard Mini – NP-BX1 – SK6812 – 10 mA-div

Each vertical increment represents the current into a single LED (at 10 mA/div), with the PWM cycles ticking along at 1.3 kHz.

The current steps aren’t the same height, because the LEDs have different forward voltages. The taller step (at the top) probably comes from the red LED, with the other two being blue and green. The maximum current is only 40 mA, not the 60 mA you’d expect with a 5 V supply.

The PWM width, of course, determines the brightness of each LED. Eyeballometrically, the average current will be half of 40 mA for (just less than) half of each PWM cycle, so figuring each SK6812 module (there’s only one here) will draw 10 mA seems reasonable.

The “base load” from the Arduino looks like 2 mA, so there’s not much point in removing its power and status LEDs.

The NP-BX1 lithium cell has lost enough capacity to no longer power my Sony HDR-AS30V helmet camera for at least half of a typical ride. The camera draws around 1 A, so you can clearly see the defunct batteries:

Sony NP-BX1 – 2018-04-24

If the average voltage during discharge is 3.3. V, then a 10 mA load would be 33 mW and a defunct NP-BX1 battery with 2 W·h capacity (at 1 A) might provide 60 hours of continuous use. I’d expect more capacity at lower current, although it’s not clear the cells actually behave that way.

So a battery-powered Vacuum Tube Light might make sense, perhaps as romantic illumination for techie snuggling:

21HB5A – Guilloche platter

Ya never know …

2019-01-28
DMM Probes

After the Great DMM Probe Debacle, I picked up similar-but-different set of cheap probes and clip leads.

The needle-tip probes carry a 20 A current rating:

No-Name DMM probes – needle tip – 20 A

If you look out along the wire, though, you’ll find a 10 A rating:

No-Name DMM probes – needle tip – 10 A wires

Now, even though 20 AWG wire in silicone may carry a 17 A spec, the corresponding 200 °C temperature seems excessive for a test probe. Limiting the current to 10 A would reduce the power dissipation by two thirds, which should limit the temperature rise. Whether the wire actually contains 20 AWG of actual copper strands remains an open question.

The kit also had banana plug / test hooks with no particular rating, although the wire allegedly has 16 AWG conductors:

DMM Clip Leads – 16 AWG

The banana plug / alligator clip combo claims 30 A, also with 16 AWG conductors. Who knows? It could be true.

For comparison, the Siglent SDM3045 DMM came with these probes:

Siglent DMM probes – 10 A

The probes carry a 10 A rating and, although the wires aren’t branded, I’ll assume they have good-enough QC to ensure the copper matches the claims. The production values seem a bit higher, too, even if they bear a striking resemblance to the cheap probes.

And, for reference, the probes with the cold solder joint also claim 20 A:

No-Name DMM probes – 20 A

Wouldn’t trust any of ’em for more than a few amps, tops …

2019-01-25
Sony HDR-AS30V Helmet Camera: MicroSD Card Spacer

Sony tried, they really tried, to make their proprietary Memory Stick flash memory cards catch on, but the slot in their HDR-AS30V Action / Helmet camera accepts both Memory Stick Micro and MicroSD cards. The two cards have slightly different sizes, the AS30V’s dual-purpose slot allows MicroSD cards to sit misaligned with the contacts, and the camera frequently kvetches about having no card.

The only solution seemed to be starting the camera while watching the display to ensure the card worked, but it would sometimes joggle out of position during a ride.

I cut out a tiny polypropylene rectangle(-ish) spacer to fill the Memory Stick side of the slot, sized to fit between the spring fingers holding the MicroSD card against its contacts:

Sony HDR-AS30V Camera – MicroSD card and spacer

Not the best cutting job I’ve ever done, but it was an iterative process and that’s where I stopped. If this works and I have need for another / better spacer, I promise to do better.

The spacer’s somewhat mottled appearance comes from tapeless sticky (an adhesive layer on a peel-off backing: inverse tape!) applied to the top side, which will affix it to the slot. I’d rather glue the spacer to the MicroSD card, but then the card wouldn’t fit in the USB 3.0 adapter I use to transfer the files.

The chips along the left edge of silkscreen come from my fingernail, because pressing exactly there seems to be the best way to force the damn thing into the proper alignment.

So the slot + spacer looks like this:

Sony HDR-AS30V Camera – dual-card slot with spacer

The MicroSD card fits in the far side of the slot, facing toward you with contacts downward, thusly:

Sony HDR-AS30V Camera – MicroSD card with spacer

And then It Just Works™, at least on the very few rides we’ve gotten in during December and early January.

Incidentally, the blue and exceedingly thin latch finger holding the battery in place will snap, should you drop the camera on its non-lens end from any height. Conversely, should you drop it on the lens end, you can kiss the optics goodbye. Your choice.

2019-01-23
Tensilizing Copper Wire

The “bus bars” on the battery holders are 14 AWG copper wire:

Astable – NP-BX1 base – detail

Slightly stretching the wire straightens and work-hardens it, which I’d been doing by clamping one end in the bench vise, grabbing the other in a Vise-Grip, and whacking the Vise-Grip with a hammer. The results tended to be, mmm, hit-or-miss, with the wires often acquiring a slight bend due to an errant whack.

I finally fished out the slide hammer Mary made when we took a BOCES adult-ed machine shop class many many years ago:

Slide Hammer

The snout captured the head of a sheet metal screw you’d previously driven into a dented automobile fender. For my simple purposes, jamming the wire into the snout and tightening it firmly provides a Good Enough™ grip:

Slide Hammer Snout

Clamp the other end of the wire into the bench vise, pull gently on the hammer to take the slack out of the wire, and slap the weight until one end of the wire breaks.

With a bit of attention to detail, the wires come out perfectly straight and ready to become Art:

Straightened 14 AWG Copper Wires

The wires start out at 1.60 mm diameter (14 AWG should be 1.628, but you know how this stuff goes) and break around 1.55 mm. In principle, when the diameter drops 3%, the area will decrease by 6% and the length should increase by 6%, but in reality the 150 mm length stretches by only 1 mm = 1%, not 3 mm. My measurement-fu seems weak.

Highly recommended, particularly when your Favorite Wife made the tool.

The Harbor Freight version comes with a bunch of snouts suitable for car repair and is utterly unromantic.

2019-01-18

Astable Multivibrator: Monochrome Pirhana LED

The LED parts box disgorged some single-color Pirhana-style LEDs:

Astable - 2N7000 - Mono Pirhana LED — Astable – 2N7000 – Mono Pirhana LED

Didn’t quite catch the blink, but the ~~Ping-Pong ball~~ radome lights up just as you’d expect.

The radome sits on a stripped-down RGB LED spider:

Astable Multivibrator Battery Holder - mono LED Spider - fit view — Astable Multivibrator Battery Holder – mono LED Spider – fit view

The circuitry is the same as the First Light version, with a 1 MΩ resistor stabilizing the LED ballast resistor:

Astable - 2N7000 - Mono Pirhana LED - detail — Astable – 2N7000 – Mono Pirhana LED – detail

Those are 1 µF ceramic caps in the astable section, so I’m no longer abusing electrolytics, and a stylin’ 100 nF film cap metering out the LED pulse up above.

Just for pretty, I’ve been using yellow / black wires for the battery connections and matching the LED color with its cathode lead.

The OpenSCAD source code as a GitHub Gist:

	// Holder for Li-Ion battery packs
	// Ed Nisley KE4ZNU January 2013
	// 2018-11-15 Adapted for 1.5 mm pogo pins, battery data table
	// 2018-12 RGB LED spider, general cleanups

	/* [Layout options] */

	BatteryName = "NP-BX1"; // [NP-BX1,NB-5L,NB-6L]

	RGBCircuit = false; // false = 1 strut pair, true = 2 pairs

	Layout = "Spider"; // [Build,Show,Fit,Case,Lid,Pins,RGBSpider,Spider]

	/* [Extrusion parameters] – must match reality! */
	// Print with +2 shells and 3 solid layers

	ThreadThick = 0.25;
	ThreadWidth = 0.40;

	HoleWindage = 0.2;

	function IntegerMultiple(Size,Unit) = Unit * ceil(Size / Unit);
	function IntegerLessMultiple(Size,Unit) = Unit * floor(Size / Unit);

	Protrusion = 0.1; // make holes end cleanly

	/* [Hidden] */

	inch = 25.4;

	BuildOffset = 3.0; // clearance for build layout

	Gap = 2.0; // separation for Fit parts

	//- Basic dimensions

	WallThick = 4*ThreadWidth; // holder sidewalls

	BaseThick = 6*ThreadThick; // bottom of holder to bottom of battery
	TopThick = 6*ThreadThick; // top of battery to top of holder

	//- Battery dimensions – rationalized from several samples
	// Coordinate origin at battery corner with contacts, key openings downward

	T_NAME = 0; // Name must fit recess, so don't get loquacious
	T_SIZE = 1;
	T_CONTACTS = 2;
	T_KEYS = 3;

	BatteryData = [
	["NP-BX1",[43.0,30.0,9.5],[[-0.75,6.0,6.2,"+"],[-0.75,16.0,6.2,"-"]],[[1.70,3.70,2.90],[1.70,3.60,2.90]]],
	["NB-5L", [45.0,32.0,8.0],[[-0.82,4.5,3.5,"-"],[-0.82,11.0,3.5,"+"]],[[2.2,0.75,2.0],[2.2,2.8,2.0]]],
	["NB-6L",[42.5,35.5,7.0],[[-0.85,5.50,3.05,"-"],[-0.85,11.90,3.05,"+"]],[[2.0,0.70,2.8],[2.0,2.00,2.8]]],
	];

	echo(str("Battery: ",BatteryName));

	BatteryIndex = search([BatteryName],BatteryData,1,0)[0];
	echo(str(" Index: ",BatteryIndex));

	BatterySize = BatteryData[BatteryIndex][T_SIZE]; // X = length, Y = width, Z = thickness
	echo(str(" Size: ",BatterySize));

	Contacts = BatteryData[BatteryIndex][T_CONTACTS]; // relative to battery edge, front, and bottom
	echo(str(" Contacts: ",Contacts));

	ContactOC = Contacts[1].y – Contacts[0].y; // + and – terminals for pogo pin contacts
	ContactCenter = Contacts[0].y + ContactOC/2;

	KeyBlocks = BatteryData[BatteryIndex][T_KEYS]; // recesses in battery face set X position
	echo(str(" Keys: ",KeyBlocks));

	//- Pin dimensions

	ID = 0;
	OD = 1;
	LENGTH = 2;

	PinShank = [1.5,2.0,6.5]; // shank, flange, compressed length
	PinFlange = [1.5,2.0,0.5]; // flange, length included in PinShank
	PinTip = [0.9,0.9,2.5]; // extended spring-loaded tip

	WireOD = 1.7; // wiring from pins to circuitry

	PinChannel = WireOD; // cut behind flange for solder overflow
	PinRecess = 3.0; // recess behind pin flange end for epoxy fill

	echo(str("Contact tip dia: ",PinTip[OD]));
	echo(str(" .. shank dia: ",PinShank[ID]));

	OverTravel = 0.5; // space beyond battery face at X origin

	//- Holder dimensions

	GuideRadius = ThreadWidth; // friction fit ridges
	GuideOffset = 7; // from compartment corners

	LidOverhang = 2.0; // atop of battery for retention
	LidClearance = LidOverhang * (BatterySize.z/BatterySize.x); // … clearance above battery for tilting
	echo(str("Lid clearance: ",LidClearance));

	CaseSize = [BatterySize.x + PinShank[LENGTH] + OverTravel + PinRecess + GuideRadius + WallThick,
	BatterySize.y + 2WallThick + 2GuideRadius,
	BatterySize.z + BaseThick + TopThick + LidClearance];
	echo(str("Case size: ",CaseSize));

	CaseOffset = [-(PinShank[LENGTH] + OverTravel + PinRecess),-(WallThick + GuideRadius),0]; // position around battery

	ThumbRadius = 10.0; // thumb opening at end of battery

	CornerRadius = 3*ThreadThick; // nice corner rounding

	LidSize = [-CaseOffset.x + LidOverhang,CaseSize.y,TopThick];

	LidOffset = [0.0,CaseOffset.y,0];

	//- Wire struts

	StrutDia = 1.6; // AWG 14 = 1.6 mm
	StrutSides = 3*4;

	StrutBase = [StrutDia,StrutDia + 4*WallThick,CaseSize.z – TopThick]; // ID = wire, OD = buildable

	//StrutOC = [IntegerLessMultiple(BatterySize.x – StrutBase[OD],5.0), // set easy OC wire spacing
	// IntegerMultiple(CaseSize.y + StrutBase[OD],5.0)];
	StrutOC = [IntegerLessMultiple(CaseSize.x – 2CornerRadius -2StrutBase[OD],5.0),
	IntegerMultiple(CaseSize.y + StrutBase[OD],5.0)];

	StrutOffset = [CaseSize.x/2 + CaseOffset.x,BatterySize.y/2]; // from case centerlines

	StrutAngle = atan(StrutOC.y/StrutOC.x);

	echo(str("Strut OC: ",StrutOC));

	//- RGB / Pirhana / Neopixel-ish LEDs

	RGBBody = [8.0,8.0,5.0]; // Z = body height

	PixelPCB = [4.0,10.0,3.0]; // Neopixel-ish PCBs, ID = chip window

	RGBPin = 5.0; // pin length
	RGBPinsOC = [5.0,5.0]; // pin layout

	RGBRecess = RGBBody.z + RGBPin/2; // maximum LED recess depth

	BallOD = 40.0; // radome sphere
	BallSides = 4*StrutSides; // nice number of sides

	BallPillar = [norm([RGBBody.x,RGBBody.y]),
	norm([RGBBody.x,RGBBody.y]) + 4*WallThick,
	StrutBase[OD] + RGBBody.z];
	BallChordM = BallOD/2 – sqrt(pow(BallOD/2,2) – (pow(BallPillar[OD],2))/4);
	echo(str("Ball chord depth: ",BallChordM));

	//———————-
	// Useful routines

	module PolyCyl(Dia,Height,ForceSides=0) { // based on nophead's polyholes

	Sides = (ForceSides != 0) ? ForceSides : (ceil(Dia) + 2);

	FixDia = Dia / cos(180/Sides);

	cylinder(r=(FixDia + HoleWindage)/2,h=Height,$fn=Sides);
	}

	//——————-
	//– Guides for tighter friction fit

	module Guides() {
	translate([GuideOffset,-GuideRadius,0])
	PolyCyl(2*GuideRadius,(BatterySize.z – Protrusion),4);
	translate([GuideOffset,(BatterySize.y + GuideRadius),0])
	PolyCyl(2*GuideRadius,(BatterySize.z – Protrusion),4);
	translate([(BatterySize.x – GuideOffset),-GuideRadius,0])
	PolyCyl(2*GuideRadius,(BatterySize.z – Protrusion),4);
	translate([(BatterySize.x – GuideOffset),(BatterySize.y + GuideRadius),0])
	PolyCyl(2*GuideRadius,(BatterySize.z – Protrusion),4);
	translate([(BatterySize.x + GuideRadius),GuideOffset/2,0])
	PolyCyl(2*GuideRadius,(BatterySize.z – Protrusion),4);
	translate([(BatterySize.x + GuideRadius),(BatterySize.y – GuideOffset/2),0])
	PolyCyl(2*GuideRadius,(BatterySize.z – Protrusion),4);

	}

	//– Contact pins
	// Rotated to put them in their natural oriention
	// Aligned to put tip base / end of shank at Overtravel limit

	module PinShape() {

	translate([-(PinShank[LENGTH] + OverTravel),0,0])
	rotate([0,90,0])
	rotate(180/6)
	union() {
	PolyCyl(PinTip[OD],PinShank[LENGTH] + PinTip[LENGTH],6);
	PolyCyl(PinShank[ID],PinShank[LENGTH] + Protrusion,6); // slight extension for clean cuts
	PolyCyl(PinFlange[OD],PinFlange[LENGTH],6);
	}
	}

	// Position pins to put end of shank at battery face
	// Does not include recess access into case

	module PinAssembly() {

	union() {
	for (p = Contacts)
	translate([0,p.y,p.z])
	PinShape();

	translate([-(PinShank[LENGTH] + OverTravel) + PinChannel/2, // solder space
	ContactCenter,
	Contacts[0].z])
	cube([PinChannel,
	(Contacts[1].y – Contacts[0].y + PinFlange[OD]),
	PinFlange[OD]],center=true);

	for (j=[-1,1]) // wire channels
	translate([-(PinShank[LENGTH] + OverTravel – PinChannel/2),
	j*ContactOC/4 + ContactCenter,
	Contacts[0].z – PinFlange[OD]/2])
	rotate(180/6)
	PolyCyl(WireOD,CaseSize.z,6);
	}
	}

	//– Case with origin at battery corner

	module Case() {

	difference() {

	union() {

	difference() {
	union() {
	translate([(CaseSize.x/2 + CaseOffset.x), // basic case shape
	(CaseSize.y/2 + CaseOffset.y),
	(CaseSize.z/2 – BaseThick)])
	hull()
	for (i=[-1,1], j=[-1,1], k=[-1,1])
	translate([i*(CaseSize.x/2 – CornerRadius),
	j*(CaseSize.y/2 – CornerRadius),
	k*(CaseSize.z/2 – CornerRadius)])
	sphere(r=CornerRadius/cos(180/8),$fn=8); // cos() fixes undersize spheres!

	for (i= RGBCircuit ? [-1,1] : -1) { // strut bases
	hull()
	for (j=[-1,1])
	translate([iStrutOC.x/2 + StrutOffset.x,jStrutOC.y/2 + StrutOffset.y,-BaseThick])
	rotate(180/StrutSides)
	cylinder(d=StrutBase[OD],h=StrutBase[LENGTH],$fn=StrutSides);

	translate([i*StrutOC.x/2 + StrutOffset.x,StrutOffset.y,StrutBase[LENGTH]/2 – BaseThick])
	cube([2*StrutBase[OD],StrutOC.y,StrutBase[LENGTH]],center=true); // blocks for fairing

	for (j=[-1,1]) // hemisphere caps
	translate([i*StrutOC.x/2 + StrutOffset.x,
	j*StrutOC.y/2 + StrutOffset.y,
	StrutBase[LENGTH] – BaseThick])
	rotate(180/StrutSides)
	sphere(d=StrutBase[OD]/cos(180/StrutSides),$fn=StrutSides);

	}
	}

	translate([-OverTravel,-GuideRadius,0])
	cube([(BatterySize.x + GuideRadius + OverTravel),
	(BatterySize.y + 2*GuideRadius),
	(BatterySize.z + LidClearance + Protrusion)]); // battery space

	translate([BatterySize.x/2,BatterySize.y/2,0]) // recess around battery name
	cube([0.8BatterySize.x,8,2ThreadThick],center=true);

	translate([CaseOffset.x + CaseSize.x/2,BatterySize.y/2,-BaseThick + ThreadThick – Protrusion]) // recess around battery name
	cube([0.75CaseSize.x,8,2ThreadThick],center=true);
	}

	Guides(); // improve friction fit

	translate([-OverTravel,-GuideRadius,0]) // battery keying blocks
	cube(KeyBlocks[0] + [OverTravel,GuideRadius,0],center=false);
	translate([-OverTravel,(BatterySize.y – KeyBlocks[1].y),0])
	cube(KeyBlocks[1] + [OverTravel,GuideRadius,0],center=false);

	translate([BatterySize.x/2,BatterySize.y/2,-ThreadThick])
	linear_extrude(height=2*ThreadThick,convexity=10)
	text(text=BatteryName,size=5,spacing=1.20,font="Arial:style:Bold",halign="center",valign="center");

	translate([CaseOffset.x + CaseSize.x/2,BatterySize.y/2,-BaseThick])
	linear_extrude(height=2*ThreadThick + Protrusion,convexity=10)
	mirror([0,1,0])
	text(text="KE4ZNU",size=6,spacing=1.20,font="Arial:style:Bold",halign="center",valign="center");
	}

	translate([2*CaseOffset.x, // battery top access
	(CaseOffset.y – Protrusion),
	BatterySize.z + LidClearance])
	cube([2CaseSize.x,(CaseSize.y + 2Protrusion),2*TopThick]);

	for (i2 = RGBCircuit ? [-1,1] : -1) { // strut wire holes and fairing
	for (j=[-1,1])
	translate([i2StrutOC.x/2 + StrutOffset.x,jStrutOC.y/2 + StrutOffset.y,0])
	rotate(180/StrutSides)
	PolyCyl(StrutBase[ID],2*StrutBase[LENGTH],StrutSides);

	for (i=[-1,1], j=[-1,1])
	translate([iStrutBase[OD] + (i2StrutOC.x/2 + StrutOffset.x),
	j*StrutOC.y/2 + StrutOffset.y,
	-(BaseThick + Protrusion)])
	rotate(180/StrutSides)
	PolyCyl(StrutBase[OD],StrutBase[LENGTH] + 2*Protrusion,StrutSides);
	}

	translate([(BatterySize.x – Protrusion), // remove thumb notch
	(CaseSize.y/2 + CaseOffset.y),
	(ThumbRadius)])
	rotate([90,0,0])
	rotate([0,90,0])
	cylinder(r=ThumbRadius,
	h=(WallThick + GuideRadius + 2*Protrusion),
	$fn=22);

	PinAssembly(); // pins and wiring

	translate([CaseOffset.x + PinRecess + Protrusion,(Contacts[1].y + Contacts[0].y)/2,Contacts[0].z])
	translate([-PinRecess,0,0])
	cube([2*PinRecess,
	(Contacts[1].y – Contacts[0].y + PinFlange[OD]/cos(180/6) + 2*HoleWindage),
	2*PinFlange[OD]],center=true); // pin insertion hole

	}

	}

	// Lid position offset to match case
	// The polarity indicator recesses are pure bodges

	module Lid() {

	union() {
	difference() {
	translate([-LidSize.x/2 + LidOffset.x + LidOverhang,LidSize.y/2 + LidOffset.y,0])
	difference() {
	hull()
	for (i=[-1,1], j=[-1,1], k=[-1,1])
	translate([i*(LidSize.x/2 – CornerRadius),
	j*(LidSize.y/2 – CornerRadius),
	k*(LidSize.z – CornerRadius)]) // double thickness for flat bottom
	sphere(r=CornerRadius,$fn=8);

	translate([0,0,-LidSize.z/2]) // remove bottom
	cube([(LidSize.x + 2Protrusion),(LidSize.y + 2Protrusion),LidSize.z],center=true);

	translate([LidSize.x/8,0,0])
	cube([LidSize.x/4,0.75LidSize.y,4ThreadThick],center=true); // epoxy recess
	}

	translate([0,0,-(Contacts[0].z + PinFlange[OD])]) // punch wire holes
	PinAssembly();

	for (n=[0,1]) // polarity recesses
	translate([-LidOverhang/2 – 0.40,Contacts[n].y,LidSize.z – ThreadThick/2])
	cube([4,4.5,ThreadThick + Protrusion],center=true);

	}

	for (n=[0,1]) // polarity indicators
	translate([-LidOverhang/2,Contacts[n].y,LidSize.z – 1*ThreadThick]) // … proud of surface
	rotate(90)
	linear_extrude(height=2*ThreadThick,convexity=10)
	text(text=Contacts[n][3],size=5,font="Arial:style:Bold",halign="center",valign="center");
	}

	}

	// Spider for RGB LED + radome atop vertical struts

	module RGBSpider() {

	difference() {
	union() {
	for (i=[-1,1], j=[-1,1]) {
	translate([iStrutOC.x/2,jStrutOC.y/2,StrutBase[OD]/2])
	rotate(180/StrutSides) // doesn't quite match crosspieces; close enough
	sphere(d=StrutBase[OD]/cos(180/StrutSides),$fn=StrutSides);
	translate([iStrutOC.x/2,jStrutOC.y/2,0])
	rotate(180/StrutSides)
	cylinder(d=StrutBase[OD],h=StrutBase[OD]/2,$fn=StrutSides);
	}

	for (m=[-1,1]) // connecting bars
	rotate(m*StrutAngle)
	translate([0,0,StrutBase[OD]/4])
	cube([norm(StrutOC),StrutBase[OD],StrutBase[OD]/2],center=true);

	translate([0,0,0]) // pillar for RGB LED and ball
	cylinder(d=BallPillar[OD],h=BallPillar[LENGTH],$fn=BallSides);
	}

	for (i=[-1,1], j=[-1,1]) // strut wires
	translate([iStrutOC.x/2,jStrutOC.y/2,-Protrusion])
	rotate(0)
	PolyCyl(StrutBase[ID],StrutBase[OD]/2,6);

	for (m=[-1,1], n=[0,1]) // RGBA wires through bars
	rotate(mStrutAngle + n180)
	translate([StrutOC.x/3,0,-Protrusion])
	PolyCyl(StrutBase[ID],StrutBase[OD],6);

	translate([0,0,BallOD/2 + BallPillar[LENGTH] – BallChordM]) // ball inset
	sphere(d=BallOD);

	translate([0,0,2*RGBBody.z + (BallPillar[LENGTH] – BallChordM) – RGBRecess]) // LED inset
	cube(RGBBody + [HoleWindage,HoleWindage,3*RGBBody.z],center=true); // XY clearance + huge height for E-Z cut

	translate([0,0,StrutBase[OD]/2]) // Neopixel recess
	PolyCyl(PixelPCB[OD],3*RGBBody.z,BallSides/2);

	for (m=[-1,1]) // RGBA wires through pillar
	rotate(m*StrutAngle)
	translate([0,0,StrutBase[OD]/2 + WireOD/2 + 0*Protrusion])
	cube([norm(StrutOC)/2,WireOD,WireOD],center=true);

	}
	}

	// Spider for single LED atop struts, with the ball
	// Aligned to struts at terminal end of battery on Y axis

	module Spider() {

	difference() {
	union() {
	for (j=[-1,1]) {
	translate([-StrutOC.x/2,j*StrutOC.y/2,StrutBase[OD]/2])
	rotate(180/StrutSides)
	sphere(d=StrutBase[OD]/cos(180/StrutSides),$fn=StrutSides);
	translate([-StrutOC.x/2,j*StrutOC.y/2,0])
	rotate(180/StrutSides)
	cylinder(d=StrutBase[OD],h=StrutBase[OD]/2,$fn=StrutSides);
	}

	translate([-StrutOC.x/2,0,StrutBase[OD]/4]) // connecting bars
	cube([StrutBase[OD]*cos(180/StrutSides),StrutOC.y,StrutBase[OD]/2],center=true);

	translate([-StrutOC.x/2,0,0]) // pillar for RGB LED and ball
	cylinder(d=BallPillar[OD],h=BallPillar[LENGTH],$fn=BallSides);
	}

	for (j=[-1,1]) // strut wires
	translate([-StrutOC.x/2,j*StrutOC.y/2,-Protrusion])
	rotate(0)
	PolyCyl(StrutBase[ID],StrutBase[OD]/2,6);

	translate([-StrutOC.x/2,0,0]) // wires through bars
	for (n=[-1,1])
	rotate(n*90)
	translate([StrutOC.x/3,0,-Protrusion])
	PolyCyl(StrutBase[ID],StrutBase[OD],6);

	translate([-StrutOC.x/2,0,-Protrusion]) // center hole for Neopixel
	rotate(180/6)
	PolyCyl(StrutBase[ID],StrutBase[OD],6);

	translate([-StrutOC.x/2,0,BallOD/2 + BallPillar[LENGTH] – BallChordM]) // ball inset
	sphere(d=BallOD);

	translate([-StrutOC.x/2,0,2*RGBBody.z + (BallPillar[LENGTH] – BallChordM) – RGBRecess]) // LED inset
	cube(RGBBody + [HoleWindage,HoleWindage,3*RGBBody.z],center=true); // XY clearance + huge height for E-Z cut

	translate([-StrutOC.x/2,0,StrutBase[OD]/2]) // Neopixel recess
	PolyCyl(PixelPCB[OD],3*RGBBody.z,BallSides/2);

	translate([-StrutOC.x/2,0,StrutBase[OD]/2 + WireOD/2 + 0*Protrusion]) // wire channels
	cube([WireOD,StrutOC.y/2,WireOD],center=true);

	}
	}

	//——————-
	// Build it!

	if (Layout == "Case")
	Case();

	if (Layout == "Lid")
	Lid();

	if (Layout == "RGBSpider") {
	RGBSpider();
	}

	if (Layout == "Spider") {
	Spider();
	}

	if (Layout == "Pins") {
	color("Silver",0.5)
	PinShape();
	PinAssembly();
	}

	if (Layout == "Fit") { // reveal pin assembly
	difference() {
	Case();

	translate([(CaseOffset.x – Protrusion),
	Contacts[1].y,
	Contacts[1].z])
	cube([(-CaseOffset.x + Protrusion),CaseSize.y,CaseSize.z]);

	translate([(CaseOffset.x – Protrusion),
	(CaseOffset.y – Protrusion),
	0])
	cube([(-CaseOffset.x + Protrusion),
	Contacts[0].y + Protrusion – CaseOffset.y,
	CaseSize.z]);
	}

	translate([0,0,BatterySize.z + Gap])
	Lid();

	color("Silver",0.15)
	PinAssembly();

	if (RGBCircuit) {
	translate([StrutOC.x/2,BatterySize.y/2,2*BatterySize.z])
	difference() {
	RGBSpider();
	rotate(180-StrutAngle)
	translate([0,0,-Protrusion])
	cube([norm(StrutOC),StrutBase[OD],2*BallPillar.z],center=false);
	}
	color("Green",0.35)
	translate([StrutOC.x/2,BatterySize.y/2,2*BatterySize.z + BallOD/2 + BallPillar[LENGTH] – BallChordM])
	sphere(d=BallOD);
	}
	else {
	difference() {
	translate([StrutOC.x/2,BatterySize.y/2,2*BatterySize.z])
	Spider();
	translate([-BallPillar[OD],BatterySize.y/2,2*BatterySize.z – Protrusion])
	cube([BallPillar[OD],StrutOC.y,2*BallPillar.z],center=false);
	}
	color("Green",0.35)
	translate([0,BatterySize.y/2,2*BatterySize.z + BallOD/2 + BallPillar[LENGTH] – BallChordM])
	sphere(d=BallOD);
	}
	}

	if (Layout == "Build") {
	rotate(90) {
	translate([-BatterySize.x/2,-BatterySize.y/2,BaseThick])
	Case();
	translate([-CaseSize.x + LidSize.x,-(LidSize.y/2 + LidOffset.y),0])
	Lid();
	if (RGBCircuit)
	translate([StrutOC.x + BatterySize.x/2,0,0])
	RGBSpider();
	else
	translate([StrutOC.x + BatterySize.x/2,0,0])
	Spider();
	}
	}

	if (Layout == "Show") {
	Case();
	translate([0,0,(BatterySize.z + Gap)])
	Lid();
	color("Silver",0.25)
	PinAssembly();
	if (RGBCircuit) {
	translate([StrutOC.x/2,BatterySize.y/2,2*BatterySize.z])
	RGBSpider();
	color("Green",0.35)
	translate([StrutOC.x/2,BatterySize.y/2,2*BatterySize.z + BallOD/2 + BallPillar[LENGTH] – BallChordM])
	sphere(d=BallOD);
	}
	else {
	translate([StrutOC.x/2,BatterySize.y/2,2*BatterySize.z])
	Spider();
	color("Green",0.35)
	translate([0,BatterySize.y/2,2*BatterySize.z + BallOD/2 + BallPillar[LENGTH] – BallChordM])
	sphere(d=BallOD);
	}
	}

view raw Astable Multivibrator Battery Holder.scad hosted with ❤ by GitHub

2019-01-17

Minilathe MT3 Spindle Collet Fitting

I’ve used the LMS set of inch-size MT3 spindle collets on occasion, but releasing them required an unseemly amount of drawbar battering. It recently occurred to me to check their fit in the spindle taper:

Minilathe – MT3 collet – taper test

Huh.

The only place they touch the spindle is right around the base, so it’s no wonder they clamp poorly and release grudgingly. I tried several others with the same result.

Cross-checking shows a much closer fit along the entire length of the dead center, so it’s not the spindle’s fault:

Minilathe – Dead Center – MT3 taper check

Stipulated: we’re not talking toolroom precision here

I set the collets on centers:

Minilathe – MT3 collet – drive setup

And proceeded to file away the offending section to move the clamping force closer to the business end of the collet:

Minilathe – MT3 collet – filed result

I did the small collets, the ones I’m most likely to need, and left the big ones for another rainy day.

They don’t have much clamping range and seem good only for exact-inch-size rods.

I should lay in a stock of ER16 and maybe ER32 collets for small stuff.

2019-01-16
