  • Floor Lamp Base: Poor Planning

    Floor lamp base - cord exit
    Floor lamp base – cord exit

    We have an old floor lamp that’s always been a bit tippy and I finally got around to wondering what’s going on.

    The cord exits through the center of the base, where it passes through a plastic nut that keeps it off the raw metal edge of the central rod holding the lamp together.

    The ruler has 1/16 inch divisions, so the cord requires a bit over half an inch of clearance.

    Floor lamp foot with bumper
    Floor lamp foot with bumper

    Here’s what one of the five molded-in feet look like, with a white rubber bumper that I just added to improve the ground clearance…

    Notice that the foot is barely 1/4 inch tall, so the lamp has always been resting on the cord and two other randomly chosen feet. No wonder the thing was tippy.

    The new rubber feet make it a lot less tippy, but there’s not a lot of clearance under there. When one of those things falls off, I’ll think of something better.

    The lamp was nominally UL approved, of course…

  • Foxconn R20-D2 Case vs. Optical Drive: Button Padding

    Extended optical drive button
    Extended optical drive button

    So I stuck a CD-RW drive into the Foxconn Atom box and discovered that the pushbutton on the front panel doesn’t move quite far enough to actually hit the corresponding button on the drive.

    Popped another drive off the heap and tried it out, just for grins, with the same result. Evidently the cute little ribbed back on the silvered panel button (near the bottom of the picture) isn’t quite long enough.

    Solution: a bit of rubberized high-traction tape stuck to the drive button (near the top of the picture).

    This is a black-on-black situation, so I pushed the contrast enough that you can actually see it.

  • Logitech Gamepad as EMC2 Pendant: Eagle Schematics for the Joggy Thing!

    Another pass at my Logitech Dual-Action Gamepad used as an EMC2 control pendant, but this time using an Eagle ULP (User Language Program) that converts a schematic into EMC2 HAL code.

    I tweaked Martin Schöneck’s original ULP a bit, added (some of the) new devices found in EMC2.4, added the corresponding Eagle symbols & devices to the library, then drew up a schematic based on my hand-hewn HAL code with some improvements. Ran the script and shazam the HAL code worked just fine (after a bit of debugging the infrastructure, of course).

    The new ULP and library are not quite ready for prime time, but this is a stick in the ground to mark some progress. You can certainly use the HAL code directly, without fiddling around in the schematic: stuff the whole program (at the end of the post) in your existing (but likely empty) custom_postgui.hal file.

    The schematic is, of course, much fluffier than the corresponding code, particularly because I chopped it into five easily printed pages. Here’s the Big Picture overview of what’s going on in each page; click the pix for bigger images.

    The servo thread interface device in the lower left provides the halui timing. The big block in the upper left has all the Logitech gamepad buttons, including the four big ones used for Z and A axis jogging. I changed the two left-rear buttons to activate the Abort signal rather than Estop, not that I use them all that much anyway.

    The two joystick knobs have pushbuttons, which I combine and use to toggle a flipflop that will select the jogging speed: fast or crawl.

    I also cut the jog deadband from 0.2 to 0.1, which makes the joysticks much more responsive.

    Logitech Gamepad HAL Schematic - Page 1
    Logitech Gamepad HAL Schematic – Page 1

    The big block on the left has all the gamepad’s analog axes. The HAT0X and HAT0Y axes correspond to the top-hat pushbuttons; they’re not really analog at all, although they take on -1.0 / 0.0 / + 1.0 floating point values. The window comparators determine which joystick axes are active, which comes in handy later on.

    Logitech Gamepad HAL Schematic - Page 2
    Logitech Gamepad HAL Schematic – Page 2

    The HAL jogging control has a single input that sets the default speed, but the proper value is vastly different depending on whether you’re jogging with linear or angular motion. This page picks out which ini file MAX_VELOCITY value to use, converts from units/sec to units/min, then does Cool Thing #1: scales the speed so that the fast/crawl speeds work out nicely.

    I use the buttons to jog rapidly from here to there, then creep up on the alignment point using the joysticks. Pressing the joysticks downward switches from Fast to Crawl speeds, which provides sort of a gearshift that’s useful for coarse / fine adjustments.

    The buttons run at two speeds:

    • Fast: the maximum speed for the axis
    • Crawl: 10% of that value

    The joysticks have a lower top speed:

    • Fast: half the maximum speed of the axis
    • Crawl: 10% of that value

    All those values go into the mux4 block and thence to the HAL jog speed control.

    Logitech Gamepad HAL Schematic - Page 3
    Logitech Gamepad HAL Schematic – Page 3

    This page does Cool Thing #2: prioritize the joystick axes and lock out the one that started moving last. The general idea is that it’s painfully easy to move the joysticks diagonally, which is great for gaming and terrible for milling machine control. A pair of flipflops for each joystick remember which axis started moving first.

    If you want to move diagonally, just press the buttons; they’re not locked out, so you can do what you want.

    Logitech Gamepad HAL Schematic - Page 4
    Logitech Gamepad HAL Schematic – Page 4

    The motion comes together on the last page, where scale blocks flip the direction of the Y and Z joystick axes so positive motion is upward. The multiplexers allow only the active axis of each joystick to reach the HAL analog jog inputs; you can vary the speed of that axis up to the maximum as you’d expect. The buttons drive the digital inputs that jog at that maximum speed; the Y and Z button directions get sorted out appropriately.

    Logitech Gamepad HAL Schematic - Page 5
    Logitech Gamepad HAL Schematic – Page 5

    Those five pages boil down into the following code, which I manually insert into my custom_postgui.hal file, along with the tool length probe pin definition.

    # HAL config file automatically generated by Eagle-CAD hal-write.ulp
    # (C) Martin Schoeneck.de 2008
    # Mods Ed Nisley 2010

    # Path: [/mnt/bulkdata/Project Files/eagle/projects/EMC2 HAL Configuration/]
    # ProjectName: [Logitech Gamepad]
    # File name: [/mnt/bulkdata/Project Files/eagle/projects/EMC2 HAL Configuration/Logitech Gamepad.hal]

    ####################################################
    # Load realtime and userspace modules
    loadrt constant	count=14
    loadrt and2	count=9
    loadrt flipflop	count=4
    loadrt mux2	count=5
    loadrt mux4	count=1
    loadrt not	count=8
    loadrt or2	count=9
    loadrt scale	count=7
    loadrt toggle	count=1
    loadrt wcomp	count=6

    ####################################################
    # Hook functions into threads
    addf toggle.0	servo-thread
    addf wcomp.1	servo-thread
    addf wcomp.2	servo-thread
    addf wcomp.3	servo-thread
    addf and2.0	servo-thread
    addf and2.4	servo-thread
    addf and2.3	servo-thread
    addf and2.2	servo-thread
    addf and2.1	servo-thread
    addf constant.6	servo-thread
    addf constant.5	servo-thread
    addf constant.4	servo-thread
    addf constant.3	servo-thread
    addf constant.2	servo-thread
    addf constant.1	servo-thread
    addf constant.0	servo-thread
    addf constant.7	servo-thread
    addf constant.8	servo-thread
    addf scale.1	servo-thread
    addf scale.2	servo-thread
    addf scale.3	servo-thread
    addf mux4.0	servo-thread
    addf mux2.0	servo-thread
    addf scale.4	servo-thread
    addf scale.0	servo-thread
    addf wcomp.5	servo-thread
    addf wcomp.4	servo-thread
    addf wcomp.0	servo-thread
    addf flipflop.1	servo-thread
    addf flipflop.0	servo-thread
    addf and2.5	servo-thread
    addf and2.6	servo-thread
    addf and2.7	servo-thread
    addf and2.8	servo-thread
    addf flipflop.2	servo-thread
    addf flipflop.3	servo-thread
    addf or2.4	servo-thread
    addf or2.8	servo-thread
    addf or2.7	servo-thread
    addf or2.6	servo-thread
    addf or2.5	servo-thread
    addf or2.3	servo-thread
    addf or2.2	servo-thread
    addf or2.1	servo-thread
    addf or2.0	servo-thread
    addf not.1	servo-thread
    addf not.2	servo-thread
    addf not.3	servo-thread
    addf not.4	servo-thread
    addf not.5	servo-thread
    addf not.6	servo-thread
    addf not.7	servo-thread
    addf not.0	servo-thread
    addf constant.9	servo-thread
    addf mux2.1	servo-thread
    addf mux2.2	servo-thread
    addf mux2.3	servo-thread
    addf mux2.4	servo-thread
    addf constant.10	servo-thread
    addf constant.11	servo-thread
    addf scale.5	servo-thread
    addf scale.6	servo-thread
    addf constant.12	servo-thread
    addf constant.13	servo-thread

    ####################################################
    # Set parameters

    ####################################################
    # Set constants
    setp constant.0.value	+0.02
    setp constant.1.value	-0.02
    setp constant.2.value	60
    setp constant.3.value	1.00
    setp constant.4.value	0.10
    setp constant.5.value	0.50
    setp constant.6.value	0.10
    setp constant.7.value	+0.5
    setp constant.8.value	-0.5
    setp constant.9.value	0.0
    setp constant.10.value	[TRAJ]MAX_LINEAR_VELOCITY
    setp constant.11.value	[TRAJ]MAX_ANGULAR_VELOCITY
    setp constant.12.value	-1.0
    setp constant.13.value	0.1

    ####################################################
    # Connect Modules with nets
    net a-button-minus input.0.btn-trigger or2.2.in0 halui.jog.3.minus
    net a-button-plus input.0.btn-thumb2 or2.2.in1 halui.jog.3.plus
    net a-buttons-active or2.2.out or2.3.in0 or2.4.in1
    net a-disable not.7.out and2.5.in1
    net a-enable flipflop.3.out not.7.in mux2.4.sel
    net a-jog wcomp.2.in input.0.abs-z-position mux2.4.in1
    net a-knob-active not.2.out or2.4.in0 and2.7.in1
    net a-knob-inactive wcomp.2.out not.2.in and2.6.in1
    net a-select and2.8.in0 and2.7.out
    net a-set flipflop.3.set and2.8.out
    net angular_motion or2.4.out mux2.0.sel
    net any-buttons-active mux4.0.sel0 or2.8.out
    net az-buttons-active or2.3.out or2.8.in1
    net az-reset flipflop.2.reset and2.6.out flipflop.3.reset
    net button-crawl scale.4.out mux4.0.in3
    net button-fast scale.2.out mux4.0.in1 scale.4.in
    net jog-crawl toggle.0.out mux4.0.sel1
    net jog-speed halui.jog-speed mux4.0.out
    net knob-crawl mux4.0.in2 scale.3.out
    net knob-fast mux4.0.in0 scale.1.out scale.3.in
    net n_1 constant.10.out mux2.0.in0
    net n_2 and2.0.in0 input.0.btn-top2
    net n_3 and2.0.in1 input.0.btn-base
    net n_4 and2.0.out halui.abort
    net n_5 halui.mode.manual input.0.btn-base3
    net n_6 wcomp.0.max wcomp.1.max wcomp.2.max wcomp.3.max constant.0.out
    net n_7 halui.program.resume input.0.btn-base4
    net n_8 wcomp.0.min wcomp.1.min wcomp.2.min wcomp.3.min constant.1.out
    net n_9 mux2.0.in1 constant.11.out
    net n_10 constant.12.out scale.5.gain scale.6.gain
    net n_11 input.0.btn-base5 or2.0.in0
    net n_12 input.0.btn-base6 or2.0.in1
    net n_13 constant.9.out mux2.1.in0 mux2.2.in0 mux2.3.in0 mux2.4.in0
    net n_14 mux2.1.out halui.jog.0.analog
    net n_15 toggle.0.in or2.0.out
    net n_16 constant.2.out scale.0.gain
    net n_17 constant.5.out scale.1.gain
    net n_18 constant.3.out scale.2.gain
    net n_19 constant.4.out scale.3.gain
    net n_20 scale.4.gain constant.6.out
    net n_21 halui.jog.1.analog mux2.2.out
    net n_22 mux2.2.in1 scale.5.out
    net n_23 scale.6.out mux2.3.in1
    net n_24 constant.13.out halui.jog-deadband
    net n_25 wcomp.4.max constant.7.out wcomp.5.max
    net n_26 constant.8.out wcomp.4.min wcomp.5.min
    net n_27 mux2.3.out halui.jog.2.analog
    net n_28 halui.jog.3.analog mux2.4.out
    net vel-per-minute scale.0.out scale.1.in scale.2.in
    net vel-per-second mux2.0.out scale.0.in
    net x-buttons-active or2.7.in0 or2.5.out
    net x-disable not.4.out and2.4.in1
    net x-enable not.4.in flipflop.0.out mux2.1.sel
    net x-hat-jog wcomp.4.in input.0.abs-hat0x-position
    net x-hat-minus wcomp.4.under or2.5.in1 halui.jog.0.minus
    net x-hat-plus or2.5.in0 wcomp.4.over halui.jog.0.plus
    net x-jog wcomp.0.in input.0.abs-x-position mux2.1.in1
    net x-knob-active not.0.out and2.1.in0
    net x-knob-inactive wcomp.0.out not.0.in and2.2.in0 and2.3.in0
    net x-set and2.1.out flipflop.0.set
    net xy-buttons-active or2.7.out or2.8.in0
    net xy-reset flipflop.0.reset and2.2.out flipflop.1.reset
    net y-buttons-active or2.6.out or2.7.in1
    net y-disable not.5.out and2.1.in1
    net y-enable flipflop.1.out not.5.in mux2.2.sel
    net y-hat-jog input.0.abs-hat0y-position wcomp.5.in
    net y-hat-minus wcomp.5.under or2.6.in1 halui.jog.1.plus
    net y-hat-plus or2.6.in0 wcomp.5.over halui.jog.1.minus
    net y-jog wcomp.1.in input.0.abs-y-position scale.5.in
    net y-knob-active not.1.out and2.3.in1
    net y-knob-inactive not.1.in wcomp.1.out and2.2.in1
    net y-select and2.4.in0 and2.3.out
    net y-set flipflop.1.set and2.4.out
    net z-button-minus input.0.btn-thumb or2.1.in0 halui.jog.2.minus
    net z-button-plus input.0.btn-top or2.1.in1 halui.jog.2.plus
    net z-buttons-active or2.1.out or2.3.in1
    net z-disable not.6.out and2.8.in1
    net z-enable not.6.in flipflop.2.out mux2.3.sel
    net z-jog wcomp.3.in input.0.abs-rz-position scale.6.in
    net z-knob-active not.3.out and2.5.in0
    net z-knob-inactive not.3.in wcomp.3.out and2.7.in0 and2.6.in0
    net z-set and2.5.out flipflop.2.set


    The ULP script that eats the schematic and poots out the HAL code:

    /******************************************************************************
     * HAL-Configurator
     *
     * Author: Martin Schoeneck 2008
     * Additional gates & tweaks: Ed Nisley KE4ZNU 2010
     *****************************************************************************/
    #usage "<h1>HAL-Configurator</h1>Start from a Schematic where symbols from hal-config.lbr are used!";

    string output_path =    "./";
    string dev_loadrt =     "LOADRT";
    string dev_loadusr =    "LOADUSR";
    string dev_thread =     "THREAD";
    string dev_parameter =  "PARAMETER";

    string dev_names[] = {
    "CONSTANT",								// must be first entry to make set_constants() work
    "ABS",				// 2.4
    "AND2",
    "BLEND",			// 2.4
    "CHARGE-PUMP",		// 2.4
    "COMP",
    "CONV_S32_FLOAT",	// 2.4
    "DDT",				// 2.4
    "DEADZONE",			// 2.4
    "DEBOUNCE",			// 2.4
    "EDGE",
    "ENCODER",			// 2.4
    "ENCODER-RATIO",	// 2.4
    "ESTOP-LATCH",
    "FLIPFLOP",
    "FREQGEN",			// 2.4
    "LOWPASS",
    "MULT2",			// 2.4
    "MUX2",
    "MUX4",				// 2.4
    "MUX8",				// 2.4
    "NEAR",				// 2.4
    "NOT",
    "ONESHOT",
    "OR2",
    "SAMPLER",			// 2.4
    "SCALE",			// 2.4
    "SELECT8",			// 2.4
    "SUM2",
    "TIMEDELAY",		// 2.4
    "TOGGLE",			// 2.4
    "WCOMP",			// 2.4
    "XOR2",				// 2.4
    ""					// end flag
    };

    string init = "# HAL config file automatically generated by Eagle-CAD hal-write.ulp\n# (C) Martin Schoeneck.de 2008\n# Mods Ed Nisley 2010\n";

    /*******************************************************************************
     * Global Stuff
     ******************************************************************************/

    string FileName;
    string ProjectPath;
    string ProjectName;

    void Info(string Message) {
    	dlgMessageBox(";<b>Info</b><p>\n" + Message);
    }

    void Warn(string Message) {
    	dlgMessageBox("!<b>Warning</b><p>\n" + Message + "<p>see usage");
    }

    void Error(string Message) {
    	dlgMessageBox(":<hr><b>Error</b><p>\n" + Message + "<p>see usage");
    	exit(1);
    }

    string replace(string str, char a, char b) {
    	// in string str replace a with b
    	int pos = -1;
    	do {
    		// find that character
    		pos = strchr(str, a);
    		// replace if found
    		if(pos >= 0) {
    			str[pos] = b;
    		}
    	} while(pos >= 0);

    	return str;
    }

    // the part name contains an index and is written in capital letters
    string get_module_name(UL_PART P) {
    	// check module name, syntax: INDEX:NAME
    	string mod_name = strlwr(P.name);
    	// split string at the : if exists
    	string a[];
    	int c = strsplit(a, mod_name, ':');
    	mod_name = a[c-1];
    	// if name starts with '[' we need uppercase letters
    	if(mod_name[0] == '[') {
    		mod_name = strupr(mod_name);
    	}

    	return mod_name;
    }

    string comment(string mess) {
    	string str = "\n\n####################################################\n";
    	if(mess != "") {
    		str += "# " + mess + "\n";
    	}

    	return str;
    }

    // if this is a device for loading a module, load it (usr/rt)
    string load_module(UL_PART P) {
    	string str = "";

    	// it's a module if the device's name starts with LOADRT/LOADUSR
    	if((strstr(P.device.name, dev_loadrt) == 0) ||
    	   (strstr(P.device.name, dev_loadusr) == 0)) {

    		// now add the string to our script
    		str += P.value + "\n";
    	}

    	return str;
    }

    // count used digital gates (and, or, etc) and load module if neccessary
    string load_blocks() {
    	string str = "";

    	int index;

    	int dev_counters[];
    	string dname[];

    	// count the gates that are used
    	schematic(S) { S.parts(P) {
    		strsplit(dname,P.device.name,'.');		// extract first part of name
    		if ("" != lookup(dev_names,dname[0],0)) {
    			for (index = 0;  (dname[0] != dev_names[index]) ; index++) {
    				continue;
    			}
    			dev_counters[index]++;
    		}
    	} }

    // force lowercase module names...

    	for (index = 0; ("" != dev_names[index]) ; index++) {
    		if (dev_counters[index]) {
    			sprintf(str,"%sloadrt %s\tcount=%d\n",str,strlwr(dev_names[index]),dev_counters[index]);
    		}
    	}

    	return str;
    }

    string hook_function(UL_NET N) {
    	string str = "";

    	// is this net connected to a thread (work as functions here)?
    	int    noclkpins       = 0;
    	string thread_name     = "";  // this net should be connected to a thread
    	string thread_position = "";
    	N.pinrefs(PR) {
    		// this net is connected to a clk-pin
    		if(PR.pin.function == PIN_FUNCTION_FLAG_CLK) {
    			// check the part: is it a thread-device?
    			if(strstr(PR.part.device.name, dev_thread) == 0) {
    				// we need the name of the thread
    				thread_name = strlwr(PR.part.name);
    				// and we need the position (position _ is ignored)
    				thread_position = strlwr(PR.pin.name);
    				thread_position = replace(thread_position, '_', ' ');
    			}
    		} else {
    			// no clk-pin, this is no function-net
    			noclkpins++;
    			break;
    		}
    	}

    	// found a thread?
    	if(noclkpins == 0 && thread_name != "") {
    		// all the other pins are interesting now
    		N.pinrefs(PR) {
    			// this pin does not belong to the thread
    			if(strstr(PR.part.device.name, dev_thread) != 0) {
    				// name of the pin is name of the function
    				//string function_name = strlwr(PR.pin.name);
    				string function_name = strlwr(PR.instance.gate.name);
    				// if functionname starts with a '.', it will be appended to the modulename
    				if(function_name[0] == '.') {
    					// if the name is only a point, it will be ignored
    					if(strlen(function_name) == 1) {
    						function_name = "";
    					}
    					function_name = get_module_name(PR.part) + function_name;
    				}
    				str += "addf " + function_name + "\t" + thread_name + "\t" + thread_position + "\n";
    			}
    		}
    	}

    	return str;
    }

    string set_parameter(UL_NET N) {
    	string str = "";

    	// is this net connected to a parameter-device?
    	int    nodotpins       = 0;
    	string parameter_value = "";
    	N.pinrefs(PR) {
    		// this net is connected to a dot-pin
    		if(PR.pin.function == PIN_FUNCTION_FLAG_DOT) {
    			// check the part: is it a parameter-device?
    //			str += "** dev name [" + PR.part.device.name + "] [" + dev_parameter + "]\n";
    			if(strstr(PR.part.device.name, dev_parameter) == 0) {
    				// we need the value of that parameter
    				parameter_value = PR.part.value;
    //				str += "**  value [" + PR.part.value +"]\n";
    			}
    		} else {
    			// no clk-pin, this is no function-net
    			nodotpins++;
    			break;
    		}
    	}

    	// found a parameter?
    	if(nodotpins == 0 && parameter_value != "") {
    		// all the other pins are interesting now
    		N.pinrefs(PR) {
    //			str += "** dev name [" + PR.part.device.name + "] [" + dev_parameter + "]\n";
    			// this pin does not belong to the parameter-device
    			if(strstr(PR.part.device.name, dev_parameter) != 0) {
    				// name of the pin is name of the function
    				//string parameter_name = strlwr(PR.pin.name);
    				string parameter_name = strlwr(PR.instance.gate.name);
    				// if functionname starts with a '.', it will be appended to the modulename
    //				str += "** param (gate) name [" + parameter_name + "]\n";
    				if(parameter_name[0] == '.') {
    					// if the name is only a point, it will be ignored
    					if(strlen(parameter_name) == 1) {
    						parameter_name = "";
    					}
    					parameter_name = get_module_name(PR.part) + parameter_name;
    //					str += "** param (part) name [" + parameter_name + "]\n";
    				}
    				str += "setp " + parameter_name + "\t" + parameter_value + "\n";
    			}
    		}
    	}

    	return str;
    }

    // if this is a 'constant'-device, set its value
    // NOTE: this is hardcoded to use the first entry in the dev_names[] array!
    string set_constants(UL_PART P) {
    	string str = "";

    	// 'constant'-device?
    	if(strstr(P.device.name, dev_names[0]) == 0) {
    		str += "setp " + get_module_name(P) + ".value\t" + P.value + "\n";
    	}

    	return str;
    }

    string connect_net(UL_NET N) {
    	string str = "";

    	// find all neccessary net-members
    	string pins = "";
    	N.pinrefs(P) {
    		// only non-functional pins are connected
    		if(P.pin.function == PIN_FUNCTION_FLAG_NONE) {
    			string pin_name =  strlwr(P.pin.name);
    			string part_name = strlwr(P.part.name);
    			pin_name =  replace(pin_name,  '$', '_');
    			part_name = replace(part_name, '$', '_');
    			pins += part_name + "." + pin_name + " ";
    		}
    	}

    	if(pins != "") {
    		string net_name = strlwr(N.name);
    		net_name = replace(net_name, '$', '_');
    		str += "net " + net_name + " " + pins + "\n";
    	}

    	return str;
    }

    /*******************************************************************************
     * Main program.
     ******************************************************************************/
    // is the schematic editor running?
    if (!schematic) {
    	Error("No Schematic!<br>This program will only work in the schematic editor.");
    }

    schematic(S) {
    	ProjectPath = filedir(S.name);
    	ProjectName = filesetext(filename(S.name), "");
    }

    // build configuration
    string cs = init + "\n\n";

    FileName = ProjectPath + ProjectName + ".hal";

    cs += "# Path: [" + ProjectPath + "]\n";
    cs += "# ProjectName: [" + ProjectName + "]\n";
    //cs += "# File name: [" + FileName + "]\n\n";

    // ask for a filename: where should we write the configuration?

    FileName = dlgFileSave("Save Configuration", FileName, "*.hal");

    if(!FileName) {
    	exit(0);
    }

    cs += "# File name: [" + FileName + "]\n\n";

    schematic(S) {
    	// load modules
    	cs += comment("Load realtime and userspace modules");
    	S.parts(P) {
    		cs += load_module(P);
    	}

    	// load blocks
    	cs += load_blocks();

    	// add functions
    	cs += comment("Hook functions into threads");
    	S.nets(N) {
    		cs += hook_function(N);
    	}

    	// set parameters
    	cs += comment("Set parameters");
    	S.nets(N) {
    		cs += set_parameter(N);
    	}

    	// set constant values
    	cs += comment("Set constants");
    	S.parts(P) {
    		cs += set_constants(P);
    	}

    	// build nets and connect them
    	cs += comment("Connect Modules with nets");
    	S.nets(N) {
    		cs += connect_net(N);
    	}
    }

    // open/overwrite the target file to save the configuration
    output(FileName, "wt") {
    	printf(cs);
    }


    Most of that script is Martin’s work; I just cleaned it up. You can download it by hovering over the code to make the little toolbar pop up near the upper-right corner of the text, then:

    • click a little button to copy it to the clipboard or
    • click another little button to view the source, then save that file

    You’ll also need the Eagle library that goes along with the script, but WordPress doesn’t like .lbr files. Here’s the hal-config-2.4.lbr file with a totally bogus odt extension. Download it, rename it to remove the .odt extension, and it’s all good.

    There is basically no documentation for any of this. I figured out what to do by looking at the source and Martin’s sample schematic, but now you have two sample schematics: the situation is definitely improving!

  • Water Bottles: Adding a Vent Plug

    Those water bottles turned out to have an unexpected feature: the vent hole dribbles when they’re laid sideways. I think it’s an unfortunate side effect of a product cheapnification: the spout is slightly concave on the side that could seal the vent, so surface tension sucks water out of the hole.

    The hole is to the right of the spout, in the center of the transverse ridge. Looks like a little black dot here; clicky for a somewhat bigger image.



    Water bottle cap showing vent hole
    Water bottle cap showing vent hole



    The solution is to put a silicone plug at the Spot Marked X on the spout, which I marked by running a small punch through the vent hole and scarring the spout. You might be able to see the tiny mark on the spout if you look closely.

    The spout comes out of the cap with a firm pull, but the sockets in the cap are obviously not intended to take much of that abuse. It’s not clear to me that the designers of these things ever take cleaning into consideration; past experience says you must completely dismantle fluid-facing components to get the crud out.

    Anyway.

    Chuck the spout up in the Sherline mill, align over the spot, and mill a 1/8 inch diameter flat-bottom hole 0.100 inch deep. The spout has a large finger-friendly flange directly underneath the Spot Marked X, so this setup isn’t quite as precarious as it looks.



    Milling socket for vent plug
    Milling socket for vent plug



    Dab in a little silicone caulk, leave a mostly flat surface standing just higher than the spout’s concavity, and we’ll see how well it works.



    Vent plug
    Vent plug



    The little nub just to the left of the new plug (on the ball-shaped part of the spout) engages the edge of the socket in the cap to sorta-kinda hold the spout closed. Doesn’t really accomplish much, but it’s a nice thought.

  • New Cutting Board: Adding Feet

    So Kohl’s sent Mary a killer deal coupon and we bought some odds and ends, including a new cutting board to replace the decades-old one that I’ve been flycutting clean every few years. Evidently bamboo is the new Right Stuff for cutting boards; it’s certainly eyeshattering.

    The thing spent the last few days soaking up a slathering of canola oil, in the hope it won’t soak up other juices.

    Recess for cutting board foot
    Recess for cutting board foot

    The instructions say to store the board standing on end so it dries properly. Evidently you’re supposed to hang it from the ring screwed into one end, but a corresponding hook (not supplied) just doesn’t doesn’t have a place on our counter / cabinet / backsplash. However, we could stand it up, leaning against an under-cabinet shelf next to the toaster oven, if only it wouldn’t slide away.

    This calls for some aftermarket tweakage!

    So I hauled it to the Basement Laboratory Woodworking Wing and installed a pair of silicone rubber feet in little recesses.

    I grabbed a 7/16-inch end-cutting end mill in the drill press, because even the manual mill doesn’t have enough height for the board on end and the drill press doesn’t have enough reach for a Forstner bit without fiddling around with the emergency drop stopper clamp. The drill press does have a good vise and an XY table, so I got it pretty close to dead center on the third dark stripe from each edge.

    The feet are about 1/4 inch tall: I went down half that in the hopes they wouldn’t bump off quite so easily.

    Silicone foot in cutting board
    Silicone foot in cutting board

    But that didn’t quite work: the adhesive on the feet doesn’t grip the rather porous endgrain bamboo nearly well enough: a foot popped off after a day. I added a layer of Genuine 3M double-stick foam tape to the feet and that’s holding just fine.

  • Arduino Mega: Voltage Regulator Heatsink

    The Arduino Mega has an SMD voltage regulator soldered to a copper pad connected with thermal vias to a similar pad on the bottom surface. The datasheet says the (roughly) 10×10 mm copper pad sets RθJA=55 °C/W, more or less; probably a bit less with the double-sided setup.

    It’s the chubby black slab snuggled up just to the right of coaxial power input jack. The four vias on each side go to an isolated copper pad under the solder mask on the other side.

    Arduino Mega voltage regulator
    Arduino Mega voltage regulator

    The board draws about 75 mA with nothing fancy on the I/O pins, so the regulator dissipates half a watt with a 12 VDC input supply. Figuring an ambient of 30 °C, the junction temperature is ticking along at 50-60 °C.

    That’s all well and good, but my rule of thumb for semiconductors is:

    • If you can’t hold your thumb on it for any length of time, it’s too damn hot.

    That regulator fails my rule of thumb even before I start adding LEDs and other doodads.

    A bit of rummaging turned up an old Thermalloy sample box with a DIP heatsink. A dab of quick-setting epoxy and there it is:

    Arduino Mega regulator with heatsink
    Arduino Mega regulator with heatsink

    Now, I’ll grant you there are a number of things wrong with that approach, but my thumb is much happier. If it gets unhappy, I’ll just crack that puppy off and stick something larger in its place.

  • Arduino Mega: Mounting Standoff and Screw

    The Arduino Mega has four, count them, four mounting holes in a more-or-less rectangular pattern around the edge of the board. Three of the four have enough room for standard pan-head 4-40 screws. The fourth hole is squeezed between two pin-header sockets, to the extent that no screw in my collection will fit.

    Screw on Arduino Mega board
    Screw on Arduino Mega board

    Having a lathe, however, makes this situation no big deal… and this time, I put the Sherline drill chuck in the 3-jaw because I wanted to, not because the 3-jaw was stuck. In truth, the lathe chuck simply won’t grab a 4-40 screw at all.

    Turning down the screw
    Turning down the screw

    I had that pointy right-cutting tool in the holder, so that’s how I cleared off the burr on the backside of the head.

    The chuck did grab the hex standoff just fine, though, and the final result looks like this…

    Modified standoff and screw for Arduino Mega
    Modified standoff and screw for Arduino Mega

    For future reference, the turned-down sections are 0.180 inch in diameter; call it 4.5 mm. The snout on the standoff must clear the pins,so it’s 0.100 inch or 2.5 mm long.
