Making and Mounting SD Card Backup Images

The process of creating, configuring, and backing up a Raspberry Pi goes a little something like this:

unzip /mnt/diskimages/ISOs/Raspberry\ Pi/2016-11-25-raspbian-jessie-lite.zip
sudo dcfldd statusinterval=16 bs=4M if=2016-11-25-raspbian-jessie-lite.img of=/dev/sdb
... Micro SD card to Pi, boot, perform various configuration tweaks ...
... card back to PC ...
sudo dcfldd statusinterval=16 bs=4M if=/dev/sdb of=Streamer5-2017-01-02.img
zip -1 Streamer5-2017-01-02.zip Streamer5-2017-01-02.img
rsync -ahuv --progress Streamer5-2017-01-02.zip /mnt/diskimages/ISOs/Raspberry\ Pi/

The ZIP operation crushes an 8 GB image down to 1.6 GB, obviously depending on most of the image being filled with binary zeros or foxes or something trivial like that. You could work around that with fsarchiver, at the cost of handling each partition separately.

You can pipe the incoming image through GZIP when you don’t need the image right away:

sudo dcfldd statusinterval=16 bs=4M if=/dev/sdb | gzip -1c > Streamer5-2017-01-02.gz

There’s an obvious gotcha when you try to write an image to a (slightly) smaller card than the one it came from. Writing a smaller image on a larger card works just fine.

With a raw image in hand, you must know the disk partition offsets within the image to mount them in loopback mode:

fdisk -l Streamer5-2017-01-02.img
Disk Streamer5-2017-01-02.img: 7.4 GiB, 7892631552 bytes, 15415296 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0xc280d360

Device                    Boot  Start      End  Sectors  Size Id Type
Streamer5-2017-01-02.img1        8192   137215   129024   63M  c W95 FAT32 (LBA)
Streamer5-2017-01-02.img2      137216 15415295 15278080  7.3G 83 Linux

Knowing the offsets, the mounts go like this:

sudo mount -o loop,offset=$(( 8192*512 )) Streamer5-2017-01-02.img /mnt/loop/
... snippage ...
sudo mount -o loop,offset=$(( 137216*512 )) Streamer5-2017-01-02.img /mnt/loop/

Because a Jessie Lite system will fit neatly into a 2 GB SD Card, you can trim the disk image to eliminate most of the unused space:

sudo losetup -f
/dev/loop0

sudo losetup /dev/loop0 Streamer5-2017-01-02.img

sudo partprobe /dev/loop0

sudo gparted /dev/loop0
... resize ext4 partition from 7 GB to 1.8 GB

sudo losetup -d /dev/loop0

fdisk -l Streamer5-2017-01-02.img
Disk Streamer5-2017-01-02.img: 7.4 GiB, 7892631552 bytes, 15415296 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0xc280d360

Device                    Boot  Start     End Sectors  Size Id Type
Streamer5-2017-01-02.img1        8192  137215  129024   63M  c W95 FAT32 (LBA)
Streamer5-2017-01-02.img2      137216 3833855 3696640  1.8G 83 Linux

truncate --size=$(( (3833855+1)*512 )) Streamer5-2017-01-02.img
... or, if you don't care about an exact fit, use ...
truncate --size=2G Streamer5-2017-01-02.img

The partition and filesystem will plump up to fill the SD Card during the first boot on the Raspberry Pi.

There exist automagic utilities for all that, but practicing simple stuff helps keep it all fresh…

2017-01-06

Xubuntu 16.04 LTS Bringup

Notes on updating my desktop Optiplex 980 from Xubuntu 14.04 LTS to 16.04 LTS, after being unable to compile OpenSCAD, Slic3r, and GNU Radio from source. Blowing three days on reconfiguration & tweakage after a clean install is the price one pays to get rid of a few years of cruft; the old version remains bootable and lootable on another partition, Just In Case.

Install:

nfs-common
xfce4-goodies
xubuntu-restricted-extras
hp2xx
xsane, xscanimage
kate (which hauls in a big hunk of wayland, alas)
digikam
chromium-browser
devilspie2
dropbox (from site)
remmina

Apply:

tweak GRUB_GFXMODE=1280x720 to make the initial menu less imposing
XFCE wide border hack, increase window title contrast in themerc
copy ssh keys
kensington & wacom button swaps in /usr/share/X11/xorg.conf.d/
firefox: media.autoplay.enabled=false, click_to_play=true
fix still-broken dropbox indicator
discard extraneous fonts, install custom fonts
copy autostart script

The hacks required to ensure NFS mounts happen before signing in seem to be obsolete. Given that systemd now controls everything, I have NFI how to proceed if that’s not the case.

The Xubuntu load progress display looks like it’s scaled up from 640×480.

There seems no way to disable on-screen notifications without deep hackery; some of the collateral damage involves the death of the volume control applet in the indicator panel thingy, so I didn’t try very hard.

The aforementioned volume control now fires up the Pulseaudio control dialog. That display explained why the audio came out of the 980’s crappy internal speaker, but switching it to the HDMI output produced only silence. After blowing away ~/.config/pulse and rebooting that sucker, it’s all good: Linux audio remains a slow-motion train wreck.

The initial sign-on dialog appears on the portrait monitor, minus rotation, because the dialog box follows the mouse pointer: the initial mouse position sits one pixel beyond the landscape monitor. Blind-type the password, whack Enter, and it’s all good.

FWIW, I’ve installed the XFCE flavor of Mint Linux on the laptops, but that’s basically Xubuntu with (some of) the ugly sanded off and really doesn’t buy much for somebody who pays no attention to eyecandy.

2017-01-05

Raspberry Pi Streaming Radio Player: Ignoring a Missing Volume Knob

The Dell AC511 USB SoundBars have volume control knobs, which this udev rule turns into the /dev/input/volume device:

ATTRS{name}=="Dell Dell AC511 USB SoundBar", SYMLINK+="input/volume"

I recently wanted to use an ordinary USB “sound card” that did not, of course, have a volume knob:

This hack skips the configuration that makes the knob’s events visible to the Python program:

import os.path

... snippage ...

# if volume control knob exists, then set up its events

VolumeDevice = '/dev/input/volume'

vp = select.poll()
if os.path.exists(VolumeDevice):
  v = InputDevice(VolumeDevice)
  v.grab()
  vp.register(v.fileno(),select.POLLIN + select.POLLPRI + select.POLLERR)

It turns out that if you never register a device with the event polling interface, then the interface never reports any events and the rest of the code remains blissfully undisturbed: the non-existent knob doesn’t do anything, while the volume control buttons on the keypad continue to function as usual.

The end result of this fiddling puts a Raspberry Pi 2 Model B to work as a streaming player on my Electronics Workbench, untethering the laptop from those powered speakers:

RPi 2 Streaming Player - USB sound gadget — RPi 2 Streaming Player – USB sound gadget

It’s a shame that USB audio gadget is so big, because it crowds out standard USB plugs to the side.

The most satisfactory LED configuration for a translucent case with an external WiFi adapter seems to be:

dtparam=pwr_led_trigger=cpu0
dtparam=act_led_trigger=mmc0

The rest of the code remains unchanged as shown in that GitHub Gist.

Bomb the bass!

2017-01-03

Loop Antenna Splice Reinforcement

Those solder joints and finicky little wires seem much too fragile on their own:

LF Loop Antenna - complete joint — LF Loop Antenna – complete joint

This should help:

Loop Antenna Splice - assembled — Loop Antenna Splice – assembled

Foam blocks hold the ribbon cable in place and provide a bit of strain relief around the hard plastic edge:

Loop Antenna Splice - hardware — Loop Antenna Splice – hardware

The brass inserts in the bottom block (on the left) got epoxied in place, because they must provide quite a bit of force to clamp the foam. Their larger knurled end sits flush with the outside surface and the smaller end has one thread thickness of clearance below the inner surface.

A last look at the wiring:

Loop Antenna Splice - wiring — Loop Antenna Splice – wiring

I think the preamp must sit at some distance from the antenna to prevent feedback, but that remains to be seen.

The M2’s nozzle accumulated a huge blob of PETG that turned into a giant smear:

Loop Antenna Splice - PETG booger — Loop Antenna Splice – PETG booger

Fortunately, it’s on the inside where nobody will ever see it. If you know where to look, it’s barely visible from the outside.

The solid model shows off the structure a bit better:

Loop Antenna Splice - show view — Loop Antenna Splice – show view

The inside view:

Loop Antenna Splice - bottom — Loop Antenna Splice – bottom

The OpenSCAD source code as a GitHub Gist:

	// Ribbon cable loop antenna splice
	// Ed Nisley KE4ZNU December 2016

	Layout = "Text";

	//- Extrusion parameters must match reality!

	ThreadThick = 0.25;
	ThreadWidth = 0.40;

	HoleWindage = 0.2;

	Protrusion = 0.1; // make holes end cleanly

	inch = 25.4;

	function IntegerMultiple(Size,Unit) = Unit * ceil(Size / Unit);

	//———-
	// Dimensions

	Cable = [200,48.0,1.5]; // X = longer than anything else

	Splice = [15.0,53.0,5.0]; // epoxy blob around joints

	Foam = [15.0,Splice[1],2.0];
	CornerRadius = 5.0;

	ID = 0;
	OD = 1;
	LENGTH = 2;

	Insert = [3.9,4.6 – 0.1,5.8]; // 4-40 knurled brass insert

	Screw = [2.7,5.5,2.0]; // OD = head LENGTH = head thickness
	Washer = [3.0,8.0,0.8];

	BlockOA = [60.0, // convenient length
	Splice[1] + 4*Washer[OD], // clearance around washer on top
	2(Insert[LENGTH] + 2ThreadThick)]; // insert sets both thicknesses

	NumScrews = 2; // screws along each side of cable
	ScrewOC = [BlockOA[0] / NumScrews,
	BlockOA[1] – 2*Washer[OD],
	2*BlockOA[2] // ensure complete holes
	];

	TextThick = 3*ThreadThick; // depth of text into surface
	TextFit = HoleWindage/2; // clearance around text polygons

	//———————-
	// Useful routines

	module PolyCyl(Dia,Height,ForceSides=0) { // based on nophead's polyholes
	Sides = (ForceSides != 0) ? ForceSides : (ceil(Dia) + 2);
	FixDia = Dia / cos(180/Sides);
	cylinder(d=(FixDia + HoleWindage),h=Height,$fn=Sides);
	}

	//—–
	// Blocky model of cable + splice + wire tap for subtraction

	module Antenna() {
	union() {
	cube(Cable,center=true);
	cube(Splice,center=true);
	for (i=[-1,1])
	translate([0,-Splice[1]/2,0])
	cube([Splice[0]/2,Splice[1],2*Foam[2]],center=true);
	}
	}

	// Outside shape of splice Block, less screw clearance

	module SpliceBlock() {
	difference() {
	hull()
	for (i=[-1,1], j=[-1,1])
	translate([i(BlockOA[0]/2 – CornerRadius),j(BlockOA[1]/2 – CornerRadius),-BlockOA[2]/2])
	cylinder(r=CornerRadius,h=BlockOA[2],$fn=4*8);
	for (i = [0:NumScrews – 1], j=[-1,1])
	translate([-BlockOA[0]/2 + ScrewOC[0]/2 + iScrewOC[0],jScrewOC[1]/2,-(BlockOA[2]/2 + Protrusion)])
	PolyCyl(Screw[ID],BlockOA[2] + 2*Protrusion,6);
	}
	}

	// Splice block less cable

	module ShapedBlock() {
	difference() {
	SpliceBlock();
	Antenna();
	}
	}

	// Bottom

	module BottomPlate() {
	difference() {
	ShapedBlock();
	translate([0,0,BlockOA[2]/2])
	cube(BlockOA + 2*[Protrusion,Protrusion,0],center=true);
	Antenna(Splice);
	for (i = [0:NumScrews – 1], j=[-1,1])
	translate([-BlockOA[0]/2 + ScrewOC[0]/2 + iScrewOC[0],jScrewOC[1]/2,-(BlockOA[2]/2 + Protrusion)])
	PolyCyl(Insert[OD],2*Insert[LENGTH],6);
	for (i=[-1,1])
	translate([i*((BlockOA[0] – Foam[0] + Protrusion)/2),0,(BlockOA[2]/2 – Cable[2]/2 – Foam[2])])
	cube([Foam[0] + Protrusion,Foam[1],BlockOA[2]],center=true);
	}
	}

	// Top

	module TopPlate() {
	difference() {
	ShapedBlock();
	translate([0,0,-BlockOA[2]/2])
	cube(BlockOA + 2*[Protrusion,Protrusion,0],center=true);
	Antenna(Splice);
	for (i=[-1,1])
	translate([i*((BlockOA[0] – Foam[0] + Protrusion)/2),0,-(BlockOA[2]/2 – Cable[2]/2 – Foam[2])])
	cube([Foam[0] + Protrusion,Foam[1],BlockOA[2]],center=true);
	rotate(90) {
	translate([0,6,BlockOA[2]/2 – TextThick])
	TextHack("KE4ZNU",8,0.0,1.15,TextThick + Protrusion);
	translate([0,-6,BlockOA[2]/2 – TextThick])
	TextHack("2016·12",6,0.0,1.20,TextThick + Protrusion);
	}
	}
	}

	module TextHack(Text="sample",Size=10,Offset=0.0,Space=1.0,Thick=ThreadThick) {
	linear_extrude(height=Thick,convexity=10)
	offset(r=Offset)
	text(Text,font=":bold",size=Size,spacing=Space,halign="center",valign="center");
	}


	//———-
	// Build them

	if (Layout == "Antenna")
	Antenna();

	if (Layout == "SpliceBlock")
	SpliceBlock();

	if (Layout == "ShapedBlock")
	ShapedBlock();

	if (Layout == "Bottom")
	BottomPlate();

	if (Layout == "Top")
	TopPlate();

	if (Layout == "Text") {
	translate([0,6,0])
	TextHack("KE4ZNU",8,-TextFit,1.15,TextThick);
	translate([0,-6,0])
	TextHack("2016·12",6,-TextFit,1.20,TextThick);
	}

	if (Layout == "Show") {
	translate([0,0,5])
	TopPlate();
	translate([0,0,-5])
	BottomPlate();
	color("Orange",0.2)
	Antenna();
	}

	if (Layout == "Build") {
	translate([0,-0.6*BlockOA[1],BlockOA[2]/2])
	rotate([180,0,0])
	TopPlate();
	translate([0,0.6*BlockOA[1],BlockOA[2]/2])
	BottomPlate();
	}

view raw Loop Antenna Splice.scad hosted with ❤ by GitHub

2016-12-27

Raspberry Pi: Forcing VNC Display Resolution

You can use VNC with a headless Raspberry Pi, but, absent a display with which to negotiate the screen resolution, X defaults something uselessly small: 720×480. To force a more reasonable resolution, edit /boot/config.txt and set the framebuffer size:

framebuffer_width=1920
framebuffer_height=1280

You can use a nonstandard resolutions, as with the 1920×1280 that fits neatly on my 2560×1440 landscape monitor, but getting too weird will surely bring its own reward. When you plug in a display, X ~~will~~ ought to negotiate as usual for the highest resolution the display can handle.

The System Configuration dialog has a “Resolution” button offering standard resolutions:

The shiny RPi Pixel UI bakes the RealVNC server directly into whatever handles the startup process these days, rendering all previous recommendations about forcing VNC resolutions inoperative. I found the trick of editing the config file on StackExchange after the usual flailing around.

Memo to Self: Remmina (the VNC client I use in XFCE on my desktop PC) doesn’t respond well to having the VNC server shut down while it’s connected. Fire up a command prompt, enter this:

sleep 10 ; sudo reboot

Then, quick like a bunny, disconnect the VNC session.

2016-12-23

Under-cabinet Lamp Brackets: Close-fit Power Plug

Adding a little tab to the angled brackets prevents them from pivoting while you’re tightening the mounting screw into the brass insert:

Kitchen Light Bracket - angled lip - Slic3r preview — Kitchen Light Bracket – angled lip – Slic3r preview

The trick with those tabs is to chop ’em off halfway to the tip, because there’s no point trying to print a wedge that ends with a sharp edge:

Kitchen Light Bracket - angled - tab cutoff - solid model — Kitchen Light Bracket – angled – tab cutoff – solid model

Generating & positioning that block goes a little something like this:

translate([0,
           2*MountBlock[1] - LEDEndBlock[2]*sin(StripAngle),
           MountBlock[2]/2 + MountHeight - 0.5*LEDEndBlock[2]*cos(StripAngle)])
    cube(2*MountBlock,center=true);

As a rule of thumb, there’s no point in fussing with smaller shapes when a big one will suffice…

This LED strip fits under the cabinet over the butcher block countertop next to the stove, which turns out to be Just Barely longer than the strip itself:

Under-cabinet light - cramped power plug — Under-cabinet light – cramped power plug

The OEM straight-on coaxial plug (near the bottom of the picture) attached to the wall wart cable obviously wouldn’t fit in the available space, so I gimmicked up a right-angle adapter by the simple expedient of shortening the solder lugs of a plug from the heap (which, admittedly, doesn’t quite fully seat in the socket), bending them sideways, soldering a pair of wires, heatshrinking appropriately, then coating wires + plug with JB Kwik epoxy. The other end of the wires gets a coaxial jack that miraculously fits the OEM plug, styled up with more heatshrink tubing. Not pretty, but nobody will ever see it.

Unlike the LED strip under the other cabinet, this IR proximity sensor doesn’t mind having a wood edge next to it and, thus, didn’t need a strip of tape to keep it happy.

2016-12-21

Under-cabinet Lamp Brackets: Angled Edition

The LED strip lights have a reasonably diffuse pattern with an on-axis bright area that puts more light on the rear of the counter than seems strictly necessary. Revising the original brackets to tilt the strips moves the bright patch half a foot forward:

Kitchen Light Bracket - angled - solid model — Kitchen Light Bracket – angled – solid model

For lack of anything smarter, the angle puts the diagonal of the LED strip on the level:

Kitchen Light Bracket - angled - Slic3r preview — Kitchen Light Bracket – angled – Slic3r preview

The translucent block represents the strip (double-thick and double-wide), with a peg punching a hole for the threaded brass insert.

Although the source code has an option to splice the middle blocks together, it can also build them separately:

Kitchen Light Bracket - angled - LED block — Kitchen Light Bracket – angled – LED block

Turns out they’re easier to assemble that way; screw ’em to the strips, then screw the strips to the cabinet.

I moved the deck screw holes to the other end of the block, thus putting the strips against the inside of the cabinet face. It turns out the IR sensor responds to the DC level of the reflected light, not short-term changes, which meant the reflection from the adjacent wood blinded it to anything waved below. Adding a strip of black electrical tape killed enough of the reflected light to solve that problem:

Under-cabinet light - IR sensor shield — Under-cabinet light – IR sensor shield

The tape isn’t quite as far off-center as it looks, but I’m glad nobody will ever see it …

The before-and-after light patterns, as viewed on B-size metric graph paper centered on the left-hand strip and aligned with the belly side of the countertop:

Under-cabinet light - straight vs angled patterns — Under-cabinet light – straight vs angled patterns

Those look pretty much the same, don’t they? So much for photography as evidence for anything.

The OpenSCAD source code as a GitHub Gist:

	// Mounting brackets for eShine under-counter LED lights
	// Ed Nisley KE4ZNU December 2016

	Layout = "Build";

	//- Extrusion parameters must match reality!

	ThreadThick = 0.25;
	ThreadWidth = 0.40;

	HoleWindage = 0.2;

	Protrusion = 0.1; // make holes end cleanly

	inch = 25.4;

	function IntegerMultiple(Size,Unit) = Unit * ceil(Size / Unit);

	//———-
	// Dimensions

	MountHeight = (1 + 03/16) inch; // distance from cabinet bottom

	THREADOD = 0;
	HEADOD = 1;
	LENGTH = 2;

	WoodScrew = [4.0,8.3,41]; // 8×1-5/8 Deck screw
	WoodScrewRecess = 3.0;
	WoodScrewMargin = 1.5 * WoodScrew[HEADOD]; // head OD + flat ring

	Insert = [3.9,4.6,5.8 + 2.0]; // 4-40 knurled brass insert

	JoinerLength = 19.0; // joiner between strips

	LEDEndBlock = [11.0,28.8,9.5]; // LED plastic end block
	LEDScrewOffset = [1.0,8.2,0]; // hole offset from end block center point

	StripAngle = atan2(LEDEndBlock[2],LEDEndBlock[1]);
	echo(str("Strip angle: ",StripAngle));

	MountBlock = [WoodScrewMargin,(WoodScrewMargin + LEDEndBlock[1]*cos(StripAngle)),MountHeight];

	//———————-
	// Useful routines

	module PolyCyl(Dia,Height,ForceSides=0) { // based on nophead's polyholes
	Sides = (ForceSides != 0) ? ForceSides : (ceil(Dia) + 2);
	FixDia = Dia / cos(180/Sides);
	cylinder(d=(FixDia + HoleWindage),h=Height,$fn=Sides);
	}

	//—–
	// LED end block with positive insert for subtraction
	// returned with mounting hole end of strip along X axis
	// ready for positioning & subtraction

	module EndBlock(Side = "L") {

	LSO = [((Side == "L") ? 1 : -1)*LEDScrewOffset[0],LEDScrewOffset[1],LEDScrewOffset[2]];

	rotate([-StripAngle,0,0])
	translate([0,LEDEndBlock[1]/2,LEDEndBlock[2]])
	union() {
	cube(LEDEndBlock + [LEDEndBlock[0],0,LEDEndBlock[2]],center=true);
	translate(LSO + [0,0,-(LEDEndBlock[2] + Insert[2])])
	rotate(180/6)
	PolyCyl(Insert[1],2*Insert[2],6);
	}
	}

	//—–
	// End mounting block with proper hole offsets

	module EndMount(Side = "L") {

	translate([0,0,MountBlock[2]/2])
	difference() {
	translate([0,MountBlock[1]/2,0])
	cube(MountBlock,center=true);

	translate([0,WoodScrewMargin,MountBlock[2]/2])
	EndBlock(Side);

	translate([0,WoodScrewMargin/2,-MountBlock[2]])
	rotate(180/6)
	PolyCyl(WoodScrew[THREADOD],2*MountBlock[2],6);

	translate([0,WoodScrewMargin/2,(MountBlock[2]/2 – WoodScrewRecess)])
	rotate(180/6)
	PolyCyl(WoodScrew[HEADOD],WoodScrewRecess + Protrusion,6);

	translate([((Side == "L") ? 1 : -1)MountBlock[0]/2,3MountBlock[1]/4,-MountBlock[2]/4])
	rotate([90,0,((Side == "L") ? 1 : -1)*90])
	translate([0,0,-2*ThreadThick])
	linear_extrude(height=4*ThreadThick,convexity=3)
	text(Side,font=":style=bold",valign="center",halign="center");
	}
	}

	module MidMount() {
	XOffset = (JoinerLength + MountBlock[0])/2;
	BridgeThick = 5.0;

	union() {
	translate([XOffset,0,0])
	EndMount("L");

	translate([0,MountBlock[1]/2,BridgeThick/2])
	cube([JoinerLength,MountBlock[1],BridgeThick] + [2*Protrusion,0,0],center=true);

	translate([-XOffset,0,0])
	EndMount("R");
	}
	}

	//———-
	// Build them

	if (Layout == "EndBlock")
	EndBlock("L");

	if (Layout == "EndMount")
	EndMount("R");

	if (Layout == "MidMount")
	MidMount();

	if (Layout == "BuildJoined") {
	translate([-(JoinerLength + 2*MountBlock[0]),0,0])
	EndMount("L");

	MidMount();

	translate([(JoinerLength + 2*MountBlock[0]),0,0])
	EndMount("R");
	}

	if (Layout == "Build") {
	translate([-MountBlock[0],0,0])
	EndMount("L");

	translate([MountBlock[0],0,0])
	EndMount("R");
	}

view raw

Kitchen Light Bracket – angled.scad

hosted with ❤ by GitHub

2016-12-20
