  • Planet Bike Superflash: Tour Easy Mount

    Having not yet gotten around to building better taillights for our bikes, we picked up some Planet Bike Superflash lights on sale. I don’t like single-LED lights, because the optics produce a concentrated beam (which is how they get such high lumen ratings) that’s essentially invisible anywhere off-axis; a taillight that requires careful alignment for maximum effect is a Bad Thing. But, eh, they were on sale…

    The graceful OEM seatpost mount, done in engineering plastic with smooth curves and something of a reputation for fragility, doesn’t work on a recumbent, so I build a butt-ugly mount that should last forever. It clamps firmly around a length of grippy silicone tape on the top seat frame rail:

    Superflash on Tour Easy
    Superflash on Tour Easy

    The reviews also complain that normal road vibrations transmitted through the somewhat whippy OEM mount pop the case apart, depositing the lens and electronics on the road behind you. Hence the black tape across the case joint.

    Here’s the whole affair on the bench:

    Superflash on mount
    Superflash on mount

    The weird color line comes from white plastic left in the extruder that covers the bottom layer or two of each part. I’m not fussy about the first pass of any new gadget, because I know I’ll build at least one more to get everything right.

    This is the first build arrangement; note the huge white teardrop blob at the start of the Skirt outline on the left. Obviously I didn’t have the initial retraction under control:

    Superflash mount on build platform
    Superflash mount on build platform

    The screw recesses built over the plate and got cute little support spiders to keep their interiors from sagging:

    Superflash mount - bolt support
    Superflash mount – bolt support

    After doing it that way, I flipped the top piece over so it builds with the screw head recesses upward to get a better finish on those nice curves. That means the arch needs support, which almost worked, although some of the fins fell over:

    Superflash mount - failed arch support
    Superflash mount – failed arch support

    The solid model now adds a two-layer-thick flat plate joining the fins that should hold them firmly to the build plate.

    Clamp Support - Solid Model
    Clamp Support – Solid Model

    I also added an option to build the flash mounting shoe separately:

    Superflash mount - solid model
    Superflash mount – solid model

    That gives better control over the flange thickness, which turns out to be critical parameter requiring a bit of adjustment with a file in the first version. Of course, the shoe needs an alignment pin and another assembly step to glue it in place:

    Superflash mount - gluing shoe
    Superflash mount – gluing shoe

    A 4-40 setscrew jams into the latch recess in the Superflash case, thus preventing it from walking off the shoe. You don’t need any particular pressure here, just enough protrusion to engage the case:

    Superflash mount - setscrew
    Superflash mount – setscrew

    The first pass at hex nut recesses were exactly cos(30) too large, as I forgot my Useful Sizes file has the across-the-points diameter, so I added a dab of epoxy to each recess before gluing the halves together with solvent:

    Superflash mount - glue clamping
    Superflash mount – glue clamping

    And then it’s all good.

    The OpenSCAD source code:

    // Planet Bike Superflash mount for Tour Easy seatback
    // Ed Nisley KE4ZNU - Dec 2011

    Layout = "Show";            // Assembly: Show
                                // Parts: Clamp Base Shoe Mount
                                // Build Plate: Build

    SeparateShoe = true;        // true = print mounting shoe separately
                                // false = join shoe to Mount block

    Support = true;             // true = include support

    Gap = 8;                    // between "Show" objects

    include </home/ed/Thing-O-Matic/lib/MCAD/units.scad>
    include </home/ed/Thing-O-Matic/Useful Sizes.scad>
    include </home/ed/Thing-O-Matic/lib/visibone_colors.scad>

    //-------
    //- Extrusion parameters must match reality!
    //  Print with +1 shells, 3 solid layers, 0.2 infill

    ThreadThick = 0.25;
    ThreadWidth = 2.0 * ThreadThick;

    HoleFinagle = 0.1;
    HoleFudge = 1.00;

    function HoleAdjust(Diameter) = HoleFudge*Diameter + HoleFinagle;

    Protrusion = 0.1;           // make holes end cleanly

    function IntegerMultiple(Size,Unit) = Unit * ceil(Size / Unit);
    function IntegerMultipleMin(Size,Unit) = Unit * floor(Size / Unit);

    //-------
    // Dimensions

    BarDia = (5/8) * inch;              // seat back rail diameter
    BarRad = BarDia/2;

    TapeThick = 0.3;                    // grippy tape around bar

    HoleDia = BarDia + 2*TapeThick;     // total hole dia
    HoleRad = HoleDia/2;
    HoleSides = 4*5;

    echo("Bar hole dia: ",HoleDia);

    TightSpace = 1.0;                   // space for tightening screws

    PlateWidth = 20.0;                  // mounting plate across flanges
    PlateLength = 20.0;                 //  ... parallel to flanges
    PlateThick = IntegerMultipleMin(1.96,ThreadThick);          //  ... thickness
    FlangeThick = IntegerMultiple(1.40,ThreadThick);            // lamp flange thickness
    FlangeWidth = 2.0;                  //  ... width

    ShoeThick = PlateThick + FlangeThick;    // dingus protruding from main block
    ShoeOffset = 1.0;                   // offset due to end wall

    echo("Shoe thickness: ",ShoeThick," = ",PlateThick," + ",FlangeThick);

    LockOffset = -5.0;                  // offset of locking setscrew

    TopRoundRad = 1.5*Head10_32/2;      // tidy rounding on top edge of clamp
    echo("Top rounding radius: ",TopRoundRad);

    NutDia = Nut10_32Dia*cos(30);       // adjust from across-points to across-flats dia
    NutPart = IntegerMultiple(0.5*Nut10_32Thick,ThreadThick);  // part of nut in each half

    BoltOffset = HoleRad + max(Head10_32,NutDia);
    BoltClear = Clear10_32;
    BoltHeadDia = Head10_32;
    BoltHeadThick = Head10_32Thick;

    MountWidth = PlateLength + ShoeOffset;         // side-to-side
    MountLength = HoleDia + 3.5*max(BoltHeadDia,NutDia);

    ClampHeight = TopRoundRad + HoleRad;            // includes gap/2 for simplicity
    BaseHeight = NutPart + HoleRad;                 //  ... likewise
    MountHeight = PlateWidth;

    echo("Mount width: ",MountWidth," length: ",MountLength);
    echo("Height of clamp: ",ClampHeight," base: ",BaseHeight," mount: ",MountHeight);
    echo(" total: ",ClampHeight+BaseHeight+MountHeight);

    AlignPegDia = 2.9;                  // shoe alignment peg
    AlignPegLength = ShoeThick;

    echo("Alignment peg length: ",AlignPegLength);

    //-------

    module PolyCyl(Dia,Height,ForceSides=0) {           // based on nophead's polyholes

      Sides = (ForceSides != 0) ? ForceSides : (ceil(Dia) + 2);

      FixDia = Dia / cos(180/Sides);

      cylinder(r=HoleAdjust(FixDia)/2,h=Height,$fn=Sides);
    }

    module ShowPegGrid(Space = 10.0,Size = 1.0) {

      Range = floor(50 / Space);

        for (x=[-Range:Range])
          for (y=[-Range:Range])
            translate([x*Space,y*Space,Size/2])
              %cube(Size,center=true);
    }

    //-------
    // Upper clamp half

    module Clamp() {

      difference() {
        translate([0,0,-TightSpace/2]) {
          difference() {
            translate([0,0,ClampHeight/2]) {
              intersection() {
                translate([0,0,-TopRoundRad])
                  minkowski() {
                    cube([(MountLength - 2*TopRoundRad),
                          (MountWidth - 2*Protrusion),
                          ClampHeight],center=true);
                    rotate([90,0,0])
                      cylinder(r=TopRoundRad,h=Protrusion,$fn=4*8);

                  }
                cube([MountLength,MountWidth,ClampHeight],center=true);
              }
            }
            translate([0,(MountWidth/2 + Protrusion)])
              rotate([90,0,0])
                PolyCyl(HoleDia,(MountWidth + 2*Protrusion),HoleSides);
            for (Index=[-1,1])
              translate([(Index*BoltOffset),0,0]) {
                translate([0,0,-Protrusion])
                  PolyCyl(BoltClear,(ClampHeight + Protrusion));
                translate([0,0,(ClampHeight - BoltHeadThick)])
                  PolyCyl(BoltHeadDia,(BoltHeadThick + Protrusion));
              }
          }

        }
        translate([0,0,-TightSpace/2])
          cube([(MountLength + 2*Protrusion),
               (MountWidth + 2*Protrusion),
               TightSpace],center=true);
      }

        if (Support)                    // choose support to suit printing orientation
          union() {
            translate([0,0,1.5*ThreadThick])
              cube([0.75*HoleDia,(MountWidth + 2*ThreadWidth),3*ThreadThick],center=true);
            intersection() {
              for (Index=[-3:3])
                translate([0,Index*(MountWidth/6),-TightSpace/2])
                  rotate([90,0,0])
                    cylinder(r=(HoleRad - 0.25*ThreadThick),
                            h=2*ThreadWidth,center=true,$fn=HoleSides);
              translate([-HoleRad,-MountWidth,0])
                cube([HoleDia,2*MountWidth,HoleRad]);
            }
          }
    }

    //-------
    // Lower clamp half = base

    module Base() {

      difference() {
        translate([0,0,-TightSpace/2])
          difference() {
            translate([0,0,BaseHeight/2])
              cube([MountLength,MountWidth,BaseHeight],center=true);
            translate([0,(MountWidth/2 + Protrusion)])
              rotate([90,0,0])
                PolyCyl(HoleDia,(MountWidth + 2*Protrusion),HoleSides);
            for (Index=[-1,1])
              translate([(Index*BoltOffset),0,0]) {
                translate([0,0,-Protrusion])
                  PolyCyl(BoltClear,(BaseHeight + Protrusion));
                translate([0,0,(BaseHeight - NutPart)])
                  rotate(30)
                    PolyCyl(NutDia,(NutPart + Protrusion),6);
    //              cylinder(r=NutDia/2,h=(NutPart + Protrusion),$fn=6);
              }
          }
        translate([0,0,-TightSpace/2])
          cube([(MountLength + 2*Protrusion),
               (MountWidth + 2*Protrusion),
               TightSpace],center=true);

      }

      if (Support)
        for (Index=[-1,1])                  // support inside nut openings
          translate([(Index*BoltOffset),
                    0,
                    (BaseHeight - (NutPart - ThreadThick) - TightSpace/2)]) {
            translate([0,0,0])
              for (Seg=[0:5]) {
                rotate(30 + 360*Seg/6)
                  cube([NutDia/2,2*ThreadWidth,NutPart - ThreadThick],center=false);
              }
          }

    }

    //-------
    // Superflash mounting shoe
    // Offset by -ShoeOffset/2 in Y to align on Mount (half of total offset on each side)

    module Shoe() {

        difference() {
          translate([-ShoeThick/2,-ShoeOffset/2,PlateWidth/2])
            if (SeparateShoe)
              cube([ShoeThick,PlateLength,PlateWidth],center=true);
            else
              cube([(ShoeThick + Protrusion),PlateLength,PlateWidth],center=true);

          translate([-(FlangeThick - Protrusion),
                    -(PlateLength/2 + ShoeOffset/2 + Protrusion),
                    (MountHeight - FlangeWidth)])
            cube([FlangeThick,(PlateLength + 2*Protrusion),(FlangeWidth + Protrusion)]);

          translate([-(FlangeThick - Protrusion),
                    -(PlateLength/2 + ShoeOffset/2 + Protrusion),
                    -Protrusion])
            cube([FlangeThick,(PlateLength + 2*Protrusion),(FlangeWidth + Protrusion)]);

          translate([-(ShoeThick + Protrusion),LockOffset,MountHeight/2])
            rotate([0,90,0])
              rotate(0)                 // align to match Mount hole orientation
                PolyCyl(Tap4_40,(ShoeThick + 2*Protrusion));

          if (SeparateShoe)
            translate([-(ShoeThick - AlignPegLength/2),0,MountHeight/2])
              rotate([0,90,0])
                PolyCyl(AlignPegDia,AlignPegLength);
        }
    }

    //-------
    // Bottom block for Superflash mount

    module Mount() {

      translate([0,0,MountHeight/2])
        union() {
          difference() {
            union() {
              translate([-MountLength/4,0,0])
                cube([MountLength/2,MountWidth,MountHeight],center=true);
              translate([((MountLength/2 - MountHeight)/2 + Protrusion),0,0])
                cube([(MountLength/2 - MountHeight + 2*Protrusion),
                     MountWidth,
                     MountHeight],center=true);
              translate([(MountLength/2 - MountHeight),0,0])
                intersection() {
                  translate([MountLength/4,0,0])
                    cube([MountLength/2,MountWidth,MountHeight],center=true);
                  translate([0,0,MountHeight/2])
                    rotate([90,0,0])
                      cylinder(r=MountHeight,h=MountWidth,center=true,$fn=4*16);
                }
            }

            translate([-(MountLength/2 + Protrusion),LockOffset,0])
              rotate([0,90,0])
                rotate(0)       // align through hole sides with point upward
                  PolyCyl(Clear4_40,(MountLength + 2*Protrusion));

            for (Index=[-1,1])
              translate([(Index*BoltOffset),0,0]) {
                translate([0,0,BaseHeight/2])
                  PolyCyl(BoltClear,(BaseHeight/2 + Protrusion));
                translate([0,0,(BaseHeight - NutPart)])
                  rotate(30)
                    PolyCyl(NutDia,(NutPart + Protrusion),6);
              }

            if (SeparateShoe)
              translate([-(MountLength/2 + AlignPegLength/2),0,0])
                rotate([0,90,0])
                  PolyCyl(AlignPegDia,AlignPegLength);
          }

          if (Support)
            for (Index=[-1,1])            // support inside nut openings
              translate([(Index*BoltOffset),0,(MountHeight/2 - (NutPart - ThreadThick))]) {
                translate([0,0,0])
                  for (Seg=[0:5]) {
                    rotate(30 + 360*Seg/6)
                      cube([NutDia/2,
                          2*ThreadWidth,
                          (NutPart - ThreadThick)],center=false);
                  }
              }

          if (!SeparateShoe)
            translate([-MountLength/2,0,-MountHeight/2])
              Shoe();
        }
    }

    //-------

    ShowPegGrid();

    if (Layout == "Clamp")
      Clamp();

    if (Layout == "Base")
      Base();

    if (Layout == "Shoe")
      Shoe();

    if (Layout == "Mount")
      Mount();

    if (Layout == "Show") {
      translate([0,0,(BaseHeight + MountHeight + Gap)]) {
        translate([0,0,TightSpace/2 + Gap])
          color(MFG) Clamp();
        translate([0,0,-TightSpace/2])
          rotate([180,0,0])
            color(DHC) Base();
      }
      translate([0,0,0])
        color(LDM) render(convexity=3) Mount();

      if (SeparateShoe)
        translate([-(MountLength/2 + Gap),0,0])
          color(DDM) Shoe();
    }

    if (Layout == "Build") {
      translate([-15,30,(BaseHeight - TightSpace/2)]) rotate([180,0,0])
        Base();
      translate([-15,00,0]) rotate([0,0,0])
        Clamp();
      if (SeparateShoe)
        translate([20,30,ShoeThick]) rotate([0,-90,180])
          Shoe();
      if (SeparateShoe)
        translate([-15,-30,MountHeight]) rotate([180,0,180])
          Mount();
      else
        translate([-15,-40,MountWidth/2]) rotate([90,0,180])
          Mount();

    }


    The original doodles, done on a retina-burning yellow scratchpad:

    Superflash Mount Doodles
    Superflash Mount Doodles
  • Acceleration Doodles

    The SJFW firmware applies acceleration limiting to motion along all four axes, so I did some doodling to come up with reasonable starting values, based on various measurements and estimates.

    Some useful background, with lots more tucked away in odd corners around here:

    Relevant equations for uniform linear acceleration a, velocity v, distance x, time t:

    • v2 – v02 = 2·a·x
    • x = (1/2)·a·t2

    X and Y Axes

    Current values with low-resistance / low-inductance steppers:

    • Decent printing at 30 mm/s = 1800 mm/min
    • Not-so-good printing at 60 mm/s = 3600 mm/min
    • Point-to-point non-printing motion at 100 mm/s

    Given that the (beefed up) XY motors can accelerate their respective stages to 100 mm/s without acceleration, assume they can reach a top speed of 200 to maybe 250 mm/s within 1 mm of travel. That’s half of the belt pitch and seems like an overestimate of the actual distance.

    • (250 mm/s)2 = 2·a·(1 mm) → a = 31000 mm/s2
    • (200 mm/s)2 = 2·a·(1 mm) → a = 20000 mm/s2

    The 1 kg Y axis probably can’t accelerate as fast as the 0.4 kg X, despite having a bigger motor.

    Z Axis

    Currently traverses at 17 mm/s = 1000 mm/min, OK at 25 mm/s, fails at 33 mm/s = 2000 mm/min. That’s with the original high-resistance / high-inductance MBI stepper without acceleration limiting.

    Typical motion will be 0.25 mm, which is 15 ms at 17 mm/s: it’s not a performance limitation.

    It’s a 4-start leadscrew that moves 8 mm/rev, so 0.25 mm = 0.031 rev. At 1/8 stepping = 1600 step/rev, that’s 50 steps. Allow 20 steps = 0.1 mm for acceleration to top speed:

    • (33 mm/s)2 = 2·a·(0.1 mm) → a = 5400 mm/s2
    • (17 mm/s)2 = 2·a·(0.1 mm) → a = 1400 mm/s2

    E Axis

    Currently runs at about 2 rev/min = 0.033 rev/s with a 9.6 mm effective drive diameter = 1 mm/s for the incoming filament. Reversal runs at 15 to 25 rev/min for about 100 ms, figure 20 rev/min = 0.33 rev/s = 10 mm/s, without acceleration limiting. The extruder has 7:51 geardown, so the motor runs at 14.6 rev/min and reverses at 146 rev/min = 2.4 rev/s = 500 step/s, none of which seems particularly challenging even in 1/1 step mode (due to using a defunct MBI stepper driver).

    That reversal speed tends to leave blobs at the end of threads, but it’s not clear the motor is up to much more acceleration. It’s a relatively small stepper, so a larger one with with more current may be needed for enough torque for faster reversal action.

    Allowing 0.1 mm to reach full speed:

    • (1 mm/s)2 = 2·a·(0.1 mm) → a = 5 mm/s2
    • (10 mm/s)2 = 2·a·(0.1 mm) → a = 500 mm/s2

    None of these numbers should be cast in stone!

    The original doodles:

    TOM286 Calibration Doodles
    TOM286 Calibration Doodles
  • Thing-O-Matic: Filament Melt Zone

    The 0.5 mm nozzle came off the hot end with surprisingly little effort; the high-temperature lube did its job! I dismantled the tensioner, clipped the filament at the top of the drive wheel, and extracted it (with the red PTFE insulation / guide tube) through the bottom of the Thermal Core. Getting the filament out of the tube required the gentle suasion of a pin punch, but eventually I found this:

    Filament melt zone - overview
    Filament melt zone – overview

    Although you can’t tell from the picture, the filament seems completely melted for about 20 mm, well-softened for another 20 mm, and soft for about 10 mm. Here’s a detail of the transition from well-softened to soft to hard:

    Filament melt zone - detail
    Filament melt zone – detail

    Notice how the notches from the drive wheel gradually fade out over about 10 mm, whereupon the filament expands to fill the PTFE tube. You can’t see the shallow depression from an air pocket offscreen at about 30 mm, but it suggests the filament isn’t quite molten from 20 mm onward. Given that the distance from the nozzle tip to the top of the Thermal Core is about 40 mm, all this makes sense, particularly when you figure the filament was stationary as the Core cooled off after the last print: the melted-to-melty sections are inside the Core and the softened section is just above the Core.

    In round numbers, the Thermal Core supplies enough heat through the PTFE tube to fully melt the filament for about 20 mm above the nozzle when printing at 2 rev/min. The effective drive diameter is 9.6 mm, so 1 rev = 9.6 π = 30 mm and the Core must melt 60 mm/min = 1 mm/s. This is obviously a grossly nonlinear situation, but if you get only 20 mm of molten filament at 1 mm/s, the maximum speed can’t be much more than 4 mm/s or so.

    The rest of the Thing-O-Matic’s mechanics set an upper limit for, say, printed octopi at 80 mm/s and 4 rev/min = 2 mm/s, but the extruder will definitely be the limiting factor for speeds over, say, 150 mm/s. Not much risk of that happening here, I’d say.

    I’ve settled on Reversal for 125 ms at 25 rev/min, so the retraction distance is:

    1.6 mm = (30 mm/rev) (0.125 s) (25 rev/min) / (60 s/min)

    That’s somewhat smaller than the 3 mm of pushback I’ve seen when swapping filaments in mid-print, but it’s in the right ballpark.

    Now, to install the 0.4 mm nozzle and recalibrate the software yet again…

  • RCA Alarm Clock Dimming

    Mary prefers dim digits on the bedroom alarm clock, far below what the usual DIM switch setting provides. I’d slipped a two-stop neutral density filter in front of our old clock’s VFD tube, but the new one has nice green LED digits that ought to have a tweakable current-setting resistor behind the switch. Indeed, a bit of surgery revealed the switch & resistors:

    RCA clock - DIM switch and resistors
    RCA clock – DIM switch and resistors

    It turns out that the 220 Ω resistors set the DIM current, with the 100 Ω resistors in parallel to set the BRIGHT current. Weirdly, the display operates in two halves: one resistor for the lower and middle segments, the other for the top segments. The resistor numbers give a hint of what the schematic might look like:

    RCA clock - LED current-set resistors
    RCA clock – LED current-set resistors

    The current control isn’t all that good, because the brightness varies with the number of active segments. With 470 Ω resistors (yes, from that assortment) in place, the variation became much more obvious; the LEDs are operating far down on their exponential I-vs-V curve. We defined the result to be Good Enough for the purpose.

    Four short screws hold the circuit board in place, but one of them arrived loosely held in a pre-stripped hole. I cut eight lengths of black Skirt filament, anointed them with solvent adhesive, dropped two apiece into each screw hole, and ran the screws back in place. I likely won’t be back in there, so it should be a lifetime fix:

    RCA clock - ABS filament in screw hole
    RCA clock – ABS filament in screw hole

    Done!

    As with all the trade names you remember from back in the Old Days, the present incarnation of “RCA” has nothing whatosever to do with the original Radio Corporation of America:

    RCA clock - data plate
    RCA clock – data plate
  • Mindless Entertainment

    Sometimes I need a task that doesn’t require a lot of thinking, like reducing the entropy of a bag of mixed SMD resistors…

    Sorting SMD Resistors
    Sorting SMD Resistors

    I’ve heard tell of  a TV-thing that serves the same purpose. Dunno when you’d have time to sort your resistors, though.

    Resistors being marked, I didn’t need those SMD tweezers.

    (Yes, this makes no sense. It’s mindless. Sometimes, ya just gotta do this stuff. OK?)

  • SMD Measurement Tweezers

    While fiddling around with those SMD capacitors, it occurred to me that I really needed some SMD tweezers: small forceps with isolated jaws, connected to the capacitance meter’s terminals. In the nature of a proof-of-concept, I sacrificed a (surplus) Tektronix banana plug cable and an old plain-steel tweezer (stamped Made in Japan back in the day when that had the same quality connotations as does Made in Pakistan right about now) and lashed them together:

    SMD tweezers - overview
    SMD tweezers – overview

    I chopped off the tweezer joint with a bolt cutter, scuffed up the steel with a file, soldered the cable wires, cut a small wood block to fit, and epoxied the whole mess together:

    SMD tweezers - epoxy joint
    SMD tweezers – epoxy joint

    When the epoxy cured, a generous wrap of silicone tape hid most of the hackage. Two lengths of clear heatstink tubing insulate the handles from my sweaty fingers:

    SMD tweezers - joint detail
    SMD tweezers – joint detail

    Part of the reason for picking this victim was its cheap-and-bendy steel: more easily soldered than stainless, no regrets about filing the jaws to suit. They’re flattened on the bottom and filed to grip SMD chips along their length:

    SMD tweezers - tip shape
    SMD tweezers – tip shape

    That’s on the top panel of my indispensable AADE LC meter. The stray capacitance of that cable is around 50 pF, but the meter can null it to a fraction of a pF. At least as long as I don’t change my grip, that is, which isn’t too severe a restriction. [Update: got the link right this time.]

    That gorgeous Tek cable turned out to be entirely too stiff and the natural curve doesn’t lie in the correct direction. The next version will probably use a length of RG-174 mini coax and a dual banana plug. I think I’d like angled jaws, too, so as to attack the chips from the top down.

    But even this version works wonderfully well, as I sorted out a few hundred random SMD caps in two half-hour sessions that I’d been putting off for far too long. This is the last batch; I’ve learned the hard way that it pays to transfer batches of chips to their storage bins long before I think I should:

    Sorting SMD caps
    Sorting SMD caps

    Yeah, it’s false economy, but it keeps me off the streets at night. OK?

  • Canon SX230HS Close-up Adapter: Up-amped LED Ring

    Paralleling a 510 Ω resistor with each of the 180 Ω resistors on the LED ring light around the macro lens holder boosted the LED string current from 15 to 20 mA:

    LED ring light - paralleled resistors
    LED ring light – paralleled resistors

    The complete botch job in the lower right is what you get when you don’t wipe the soldering iron tip first.

    LED brightness being pretty nearly linearly proportional to current, the exposure gets another 0.4 EV that probably doesn’t matter in the least.

    A hand-held picture of the pile of SMD resistors (which willingly produced four of the five resistors and required enhanced interrogation to extract the last one):

    SX230HS - macro lens - 15 x 20 mA ring light
    SX230HS – macro lens – 15 x 20 mA ring light

    That’s pretty much overhead at f/8, so the depth of field is as good as it gets.
