  • Kenmore 158: Acceleration and Deceleration

    Plotting the motor RPM every 500 ms while increasing the nominal current by 50 mA per step from 550 mA:

    Motor RPM vs Current Steps - Accelerating
    Motor RPM vs Current Steps – Accelerating

    And then downward from 950 mA:

    Motor RPM vs Current Steps - Decelerating
    Motor RPM vs Current Steps – Decelerating

    No, the steps aren’t the same size going down as they are going up. The nominal current setting is open-loop = constant DAC values: the actual current for a given DAC value varies as the transistors heat up.

    The motor starts running at 3700 RPM with 550 mA and stops well under 1000 RPM with 400 mA. Obviously, starting slowly and smoothly will require finesse: a swift kick of maybe 600 mA to get it turning, then immediately drop to 400-ish mA for slow stitching. Those currents must be the actual motor current, not the nominal DAC values, so the motor sees the proper current regardless of the transistor temperature.

    The sewing machine requires four samples = two seconds to stabilize at each new speed on the way up, so the mechanical time constant is 2/3 second. Trying to stabilize the speed with a loop running much faster than that will certainly cause oscillation.

    There is absolutely no deceleration control authority: reducing the current allows freewheeling as the machinery slows down to match the current. The undershoot after each step on the way down lasts 2.5 s, then there’s a persistent oscillation with a period of 3 s.

    Forcing the firmware to run slowly enough to match the hardware should pose an interesting challenge… you don’t want to lock up the UI while the motor stabilizes!

  • Kenmore 158: Current Sensor Calibration

    The first task: produce an equation that converts raw ADC values into actual motor current. This is not quite the same as the DC calibration, because the motor current is neither clean nor stable.

    Step the output current setpoint in 50 mA increments from 450 mA to 1100 mA and remain at each setpoint for 10 seconds while dumping measurements every 500 ms. The ADC count comes from the sampling / sorting / selection process that attempts to pick out either the not really flat top of the current-limited waveform or the peak of the non-limited sine wave.

    Convert the raw data dump into a spreadsheet to get a block like this for each current setpoint:

    Motor RPM Shaft RPM Setpoint mA DAC count ADC count Noisy mA Comp mA
    Setpoint: 600 DACvalue: 2372
    3797 334 600 2372 266 724 540
    4465 399 600 2372 263 715 532
    4734 416 600 2372 265 721 538
    4834 438 600 2372 263 715 532
    4829 433 600 2372 264 718 535
    4857 438 600 2372 264 718 535
    4900 438 600 2372 265 721 538
    4859 436 600 2372 266 724 540
    4887 445 600 2372 265 721 538
    4926 446 600 2372 263 715 532
    4884 438 600 2372 265 721 538
    4890 442 600 2372 264 718 535
    4913 440 600 2372 264 718 535
    4866 436 600 2372 263 715 532
    4895 434 600 2372 264 718 535
    4890 442 600 2372 266 724 540
    4884 438 600 2372 266 724 540
    4913 442 600 2372 265 721 538
    4913 441 600 2372 266 724 540
    4878 436 600 2372 264 718 535
    265

    The lone number on the bottom row is the computed average of the ADC counts for the block, which I did in the spreadsheet rather than in the firmware.

    During each ten second interval, set the scope voltage cursor to the eyeballed “correct” value of the motor current waveform, as measured on the Tek current probe. There’s no way to automate this, because only the human eyeball can pick out the, ah, true current measurement amid all the clutter:

    Calibrate - Hall amp - Tek 200 mA-div
    Calibrate – Hall amp – Tek 200 mA-div

    For each current setpoint value, create a line with the manually measured true voltage from the scope trace, the calculated true current (using the Tek probe’s front panel scale), along with the DAC setpoint and the average ADC values extracted from each block of that giant data dump:

    Setpoint mA Scope mV Actual mA DAC count ADC count
    450 21.80 436 2205 197
    500 25.94 519 2261 225
    550 29.06 581 2316 245
    600 31.56 631 2372 265
    650 34.38 688 2427 285
    700 36.88 738 2483 304
    750 39.69 794 2538 324
    800 42.19 844 2594 340
    850 45.00 900 2649 350
    900 47.50 950 2705 361
    850 46.86 937 2649 356
    800 43.75 875 2594 348
    750 41.25 825 2538 335
    700 39.06 781 2483 318
    650 36.56 731 2427 302
    600 34.38 688 2372 285
    550 32.50 650 2316 270
    500 30.31 606 2261 253
    450 27.81 556 2205 237
    400 25.63 513 2150 220

    Plot each actual motor current against the corresponding average ADC value:

    ADC Calibration Curve
    ADC Calibration Curve

    The linear fit breaks down toward 1 A, because measuring the actual peak of a noisy sine wave doesn’t work well, but the values aren’t all that far off.

    Given an ADC value, that equation converts it directly into the actual motor current as estimated by the human eyeball, taking into account all the measurement weirdness. The Hall sensor produces a voltage that’s linearly related to the current, so the reasonable linearity of the data says that the sampling / sorting / selection process actually produces pretty nearly the correct result across the entire operating current range.

    Note that the equation doesn’t depend on the DAC output calibration; the ADC and Tek probe simply measure whatever current happens to pass through the motor for that DAC value. The current through the ET227 transistor doesn’t seem to change over the ten seconds required to take the manual measurement, so it’s all good.

  • Wasabi NB-5L: Underperformers

    Based on the poor performance of the NB-5L batteries I bought from Blue Nook, they sent me three NB-5L batteries from a fresh batch (date code BNI13) and I ran them through the same discharge test:

    Canon NB-5L - OEM Wasabi - 2014-10-29
    Canon NB-5L – OEM Wasabi – 2014-10-29

    The red line off to the far right is the three year old Canon OEM battery, which remains far and away the best battery at 1 A·h.

    The previous cells (BNF27) produced the three scattered traces with the lowest initial voltages, ending around 0.8 A·h.

    The new cells (BNI13) produced the three tightly clustered traces. They have a higher initial voltage than the OEM cell, but much lower total capacity (about 0.75 A·h).

    These batteries obviously don’t come close to their 1400 mA·h rating. The capacity depends on the load current, but I’m using 500 mA because that’s close to the camera’s drain; the results should correlate reasonably well with actual use.

    The higher voltage from the new batteries will produce a longer runtime than the previous duds, but their total capacity is lower and they’re still no match for the old Canon OEM battery.

    The new ones start out very similar to each other, but the previous batch hasn’t aged well on their shelf. If the date codes mean what I think, all of these batteries will fail quickly.

    All that’s quite disappointing, because their NP-BX1 batteries for the Sony camera turned out quite well. The date codes all have the same format and typography, so I think they come from the same factory.

    For whatever it’s worth, I think the date coding works like this:

    • B – factory? shift? OEM? Blue Nook?
    • M – last two digits of year: M=13, N=14
    • K – month: F=6, I=9, K=11
    • 20 – day

    For the four batteries / lots I have on hand:

    • BMK20 = 2013 Nov 20 – NP-BX1 bought in early 2014
    • BNI18 = 2014 Sep 18 – NP-BX1 bought in October – new lot
    • BNF27 = 2014 Jun 27 – NB-5L bought in October – old lot
    • BNI13 = 2014 Sep 13 – NB-5L supplied in late October – new lot

    So it goes.

  • Kenmore 158: Bubble Sorted Motor Current Sampling

    Because the ET227 transistor acts as a current limiter, the motor current waveform has flat tops at the level set by the DAC voltage. However, the current depends strongly on the temperature of all those transistor junctions, with some commutation noise mixed in for good measure, so the firmware must measure the actual current to know what’s going on out there.

    Here’s one way to pull that off:

    Motor current - ADC sample timing
    Motor current – ADC sample timing

    The upper waveform shows the motor current sporting flat tops at 650 mA.

    The lower waveform marks the current measurement routine, with samples taken just before the falling edge of the first nine pulses. The (manually tweaked) delay between the samples forces them to span one complete cycle of the waveform, but they’re not synchronized to the power line. Remember that the motor runs from a full wave rectifier, so each “cycle” in that waveform is half of a normal power line cycle.

    Given an array containing those nine samples, the routine must return the maximum value of the waveform, ignoring the little glitch at the start of the flat top and taking into consideration that the waveform won’t have a flat top (or much of a glitch) when the current “limit” exceeds the maximum motor current.

    After a bit of fumbling around with the scope and software, the routine goes like this:

    • Collect samples during one current cycle
    • Sort in descending order
    • Ignore highest sample
    • Return average of next two highest samples

    Given that the array has only nine samples, I used a quick-and-dirty bubble sort. The runt pulse at the end of the series in the bottom waveform brackets the sort routine, so it’s not a real time killer.

    Seeing as how this is one of the very few occasions I’ve had to sort anything, I wheeled out the classic XOR method of exchanging the entries. Go ahead, time XOR against swapping through a temporary variable; it surely doesn’t make any difference at all on an 8-bit microcontroller.

    The sampling code, with all the tracing stuff commented out:

    //------------------
    // Sample current along AC waveform to find maximum value
    //	this is blocking, so don't call it every time around the main loop!

    #define NUM_I_SAMPLES	9

    unsigned int SampleCurrent(byte PinNum) {

    unsigned int Samples[NUM_I_SAMPLES];
    unsigned int AvgSample;
    byte i,j;

    //	digitalWrite(PIN_SYNC,HIGH);
    	for (i=0; i < NUM_I_SAMPLES; i++) {				// collect samples
    //		digitalWrite(PIN_SYNC,HIGH);
    		Samples[i] = ReadAI(PinNum);
    //		digitalWrite(PIN_SYNC,LOW);
    		delayMicroseconds(640);
    	}
    //	digitalWrite(PIN_SYNC,LOW);

    //	digitalWrite(PIN_SYNC,HIGH);							// mark start of sorting
    	for (i=0; i < (NUM_I_SAMPLES - 1); i++)
    		for (j=0 ; j < (NUM_I_SAMPLES - 1 - i); j++)
    			if (Samples[j] < Samples[j+1]) {
    				Samples[j] ^= Samples[j+1];					// swap entries!
    				Samples[j+1] ^= Samples[j];
    				Samples[j] ^= Samples[j+1];
    			}
    //	digitalWrite(PIN_SYNC,LOW);								// mark end of sorting

    //	printf("Samples: ");
    //	for (i=0; i < NUM_I_SAMPLES; i++)
    //		printf("%5d,",Samples[i]);

    	AvgSample = (Samples[1] + Samples[2])/2;				// discard highest sample
    //	printf(" [%5d]\r\n",AvgSample);

    	return AvgSample;

    }

  • Kenmore 158: Motor RPM and Shaft Sensor First Light

    Using basically the same Arduino firmware as before, so the pedal scales the motor current without feedback:

    Curr Sense RPM Spindle Pos
    Curr Sense RPM Spindle Pos

    The top trace is the motor current, sampled through the ferrite toroid / Hall effect sensor / differential amp, at about 525 mA/V, so the current limit along those flat tops is 630 mA. There’s a small initial spike leading into each flat top, where (I think) the rapidly rising collector voltage rams enough current through the Miller capacitance into the base to briefly push the collector current upward.

    The next trace is the motor RPM sensor, ticking along at 14 revolutions in 160 ms = 87.5 rev/s = 5250 RPM. The glitch toward the right side comes from me hitting the scope’s STOP button to freeze the display in mid-trace. There’s no trace of the setscrew glitch, although that may be due to the compressed scale rather than the absence of the glitch.

    The bottom trace is the shaft position sensor, with 1 rev in 125 ms = 8 rev/s = 480 RPM. It’s nicely divided into equal halves, which is what you’d expect from looking at the counterweight.

    Under these conditions the speed ratio works out to 10.93, a whopping 9% over my original guesstimate.
