Although those pink clamp platesworked well enough, they did not provide, shall we say, a completely satisfactory user experience. I reprinted new sets in red while varying the extruder speed by 0.1 rev/min, with small tweaks to the overlap between the infill and the loop threads.
First, the big pictures with details scrawled on the back of the lower plate…
At 3.2 rpm, which is only slightly too fast:
Fairing Plate – 3.2 rpm
At 3.3 rpm, a bit overstuffed:
Fairing Plate – 3.3 rpm
At 3.4 rpm, there’s obviously too much plastic:
Fairing Plate – 3.4 rpm
Some closeups, in the same order…
At 3.2 rpm with 0.20 overlap, it looks OK:
Fairing Plate – 3.2 rpm detail
At 3.3 rpm with 0.25 overlap, which pretty much devours the inner loop thread:
Fairing Plate – 3.3 rpm detail
At 3.4 rpm with 0.25 overlap there’s serious overfill:
Fairing Plate – 3.4 rpm detail
In all cases, the extruder left a track while exiting upward from near the middle of the images. Even at 3. 2 rpm there’s slightly too much plastic.
My ladies don’t care about the fine details. They prefer red to pink and the clamps hold the fairings firmly in place…
Those plates handle the upper mount points, but the fairing also attaches to each side of the front fork. A nice rounded oval mates the fairing to the bracket, with two foam pads adapting the flat plates to the curved fairing surface. This view shows the outside of the fairing:
Lower mount – front
The hole position requires a mirror-image pair of mounts that, mercifully, all fit on the build platform at once. The solid models look about like you’d expect:
Lower Bushings
Those little tabs on the inside edge of the bracket recess printed about as poorly as you’d expect, but they’re not really critical.
I printed a set of white plates for my bike, installed the new filament tensioner, and went full frontal Barbie for my favorite ladies. This view shows the inside of the fairing:
Lower mount – rear
Turns out my ladies don’t like pink any more than I do.
The OpenSCAD source:
// Clamp plates for Zzipper fairing on Tour Easy recumbents
// Ed Nisley - KE4ZNU - Mar 2011
// Build with...
// extrusion parameters matching the values below
// 4 outer shells
// 4 solid surfaces at top + bottom
include </home/ed/Thing-O-Matic/lib/MCAD/units.scad>
// Extrusion parameters for successful building
ThreadWidth = 0.55; // should match extrusion width
ThreadZ = 0.33; // should match extrusion thickness
HoleWindage = ThreadWidth; // enlarge hole dia by extrusion width
// Plate dimensions
Layer1X = 35; // against fairing surface
Layer1Y = 30;
Layer1Z = 2*ThreadZ;
HoleOffsetX = 5.0; // will be sign-flipped as needed
HoleOffsetY = -(Layer1Y/2 - 10.0);
Layer2Margin = 1.5; // uncovered edge
Layer2X = Layer1X - 2*Layer2Margin;
Layer2Y = Layer1Y - 2*Layer2Margin;
Layer2Z = 3*ThreadZ;
MountX = 16.3 + HoleWindage; // front fork mounting plate
MountHoleOffset = 13.0; // Y end to hole center
MountY = Layer1Y;
MountZ = 4*ThreadZ; // recess depth
MountCap = 3.0; // endcap arc height
MountR = (pow(MountCap,2) + 0.25*pow(MountX,2)) / (2*MountCap); // ... radius
Layer3Margin = 1.5;
Layer3X = Layer2X - 2*Layer3Margin;
Layer3Y = Layer2Y - 2*Layer3Margin;
Layer3Z = 3*ThreadZ;
PlateZ = Layer1Z + Layer2Z + Layer3Z;
HoleDia = 0.25 * inch; // these are 1/4-20 bolt holes
// Convenience settings
BuildOffsetX = 3.0 + Layer1X/2; // build X spacing between top & bottom plates
BuildOffsetY = 3.0 + Layer1Y/2; // ... Y
Protrusion = 0.1; // extend holes beyond surfaces for visibility
//---------------
// Create plate
module Plate() {
union() {
translate([0,0,Layer1Z/2])
scale([Layer1X,Layer1Y,1]) cylinder(r=0.5,h=Layer1Z,$fn=32,center=true);
translate([0,0,Layer1Z + Layer2Z/2])
scale([Layer2X,Layer2Y,1]) cylinder(r=0.5,h=Layer2Z,$fn=32,center=true);
translate([0,0,Layer1Z + Layer2Z + Layer3Z/2])
scale([Layer3X,Layer3Y,1]) cylinder(r=0.5,h=Layer3Z,$fn=32,center=true);
}
}
//---------------
// Create hole
module Hole(OffsetX,OffsetY) {
translate([OffsetX,OffsetY,PlateZ/2])
cylinder(r=(HoleDia + HoleWindage)/2,
h=(PlateZ + 2*Protrusion),
center=true,$fn=10);
}
//---------------
//-- Build the things...
// Right side
translate([BuildOffsetX,BuildOffsetY,0])
difference() {
Plate();
Hole(HoleOffsetX,HoleOffsetY);
}
translate([BuildOffsetX,-BuildOffsetY,0])
difference() {
Plate();
Hole(-HoleOffsetX,HoleOffsetY);
translate([-HoleOffsetX,(HoleOffsetY - MountY/2 + MountHoleOffset),(PlateZ - MountZ/2 + Protrusion/2)])
intersection() {
cube([MountX,MountY,(MountZ + Protrusion)],center=true);
translate([0,(MountY/2 - MountR),0]) cylinder(r=MountR,h=(MountZ + Protrusion),center=true);
}
}
// Left side
translate([-BuildOffsetX,BuildOffsetY,0])
difference() {
Plate();
Hole(-HoleOffsetX,HoleOffsetY);
}
translate([-BuildOffsetX,-BuildOffsetY,0])
difference() {
Plate();
Hole(HoleOffsetX,HoleOffsetY);
translate([HoleOffsetX,(HoleOffsetY - MountY/2 + MountHoleOffset),(PlateZ - MountZ/2 + Protrusion/2)])
intersection() {
cube([MountX,MountY,(MountZ + Protrusion)],center=true);
translate([0,(MountY/2 - MountR),0]) cylinder(r=MountR,h=(MountZ + Protrusion),center=true);
}
}
Just fixed a flat on my bike which, like that one, came from the tire liner chewing through the tube. The holes are above the raised 28″ molded into the tube, at the upper-left corner of the tire liner impression.
Schwalbe tube with tire liner abrasion
In this case, the tire liner (which, judging from the color, was a Slime) was too short by maybe 50 mm. This view inside the tire shows a 10 mm gap where the ends didn’t overlap as they should:
Schwalbe Maration tire with liner abrasion
I don’t trim the rear-tire liners, but comparing a handful in the drawer shows that the as-sold lengths differ by a few tens of millimeters. The Marathons are husky tires, but the tread OD isn’t all that much different from stock tires: that’s the definition of a 700-series tire.
That we’re getting repeated flats from tire liners intended to eliminate flats is, mmmm, disturbing. Looking at the condition of the tire treads, however, shows we’re not getting an order of magnitude more flats from road debris, so it’s a net win. I doubt we could get through a month of riding without a flat; I replace tires when the carcasses accumulate enough gashes that the tire liners begin extruding through the tread.
Also, remember that these samples come from three bikes that travel upwards of 2000 miles a year (each!), not just one bike ridden along a nice rail trail on weekends…
The stock Zzipper fairing handlebar mount consists of an aluminum bar with a plate welded to each end at more-or-less the correct angle to match the fairing curve. The plate has a 1/4 inch hole in one end, wherein a 1/4-20 nylon machine screw clamps the fairing to the plate, with a nylon washer distributing the stress. That doesn’t cope well with the vibrations caused by riding around here, let alone our summer vacation trips on crushed-stone rail trails, and the fairings tend to stress-crack at the holes.
These 3D printed plates are just the latest in a long series of attempts to distribute the stress over a larger area. The outside view:
Fairing mount – outside
The open hole gets another screw to hold the plates in position. The bump on the far side is an Oozebane turd, about which more later.
The view from inside the fairing:
Fairing mount – inside
You can’t see the layer of black foam rubber salvaged from a mouse pad between each plate and the fairing. That should prevent any local stress concentration at the screw and ease the transition to the tapered plate edges.
The solid model looks about like you’d expect:
Fairing Mount Plates – Upper
The hole position depends on the fairing position, as the fairings have three holes. The pictures show the fairing on my bike; it’s in the lowest position, with the screw in the topmost hole. The OpenSCAD file has an option to put the holes where you need them.
The plates are only 8 layers thick, printed with 4 solid layers top and bottom to eliminate any fill. You could do the same by setting the fill to 100%, I suppose. Using 4 outer shells (3 additional) makes the flanged edge nice and flat and uniform.
The layer height is 0.33 mm, with w/t=1.7 for a width of 0.56 mm. Feed rate = 43 mm/s and flow rate = 255. DC Extruder, alas.
Running the first layer at feed = 0.5 and flow = 0.75 produces some fluffing in the fill, but there’s no way to get a lower flow from the DC extruder motor. Flow = 0.75 corresponds to PWM=191; anything lower sometimes fails to start the motor. If it starts, it’ll run, but … that’s not dependable.
I printed them on an aluminum plate for a nice flat bottom surface.
The OpenSCAD source code:
// Clamp plates for Zzipper fairing on Tour Easy recumbents
// Ed Nisley - KE4ZNU - Mar 2011
// Build with...
// extrusion parameters matching the values below
// 4 outer shells
// 4 solid surfaces at top + bottom
// slow feeds to ensure hole perimeters stick to fill
include </home/ed/Thing-O-Matic/lib/MCAD/boxes.scad>
include </home/ed/Thing-O-Matic/lib/MCAD/units.scad>
// Select hole layout
// The if statement seems to work only for CSG object trees
// Fortunately, I need only two different layouts...
HoleSelect = 1; // 0 = his, 1 = hers
HolesTop = (0 == HoleSelect) ? [0,1,1] : [1,0,1];
HolesBottom = (0 == HoleSelect) ? [0,1,1] : [1,0,1];
// Set these to match the extrusion parameters for successful building
ThreadZ = 0.33; // extrusion thickness
ThreadWidth = 0.57; // extrusion width = ThreadZ x w/t
HoleWindage = ThreadWidth; // enlarge hole dia by extrusion width
// Plate dimensions
HoleDia = 0.25 * inch; // these are 1/4-20 bolt holes
HoleSpace = (1) * inch; // center-to-center spacing
// usually 1 inch, but 15/16 on one bike
CornerR = 5.0; // corner rounding
Layer1X = 90; // against fairing surface
Layer1Y = 32;
Layer1Z = 2*ThreadZ;
Layer2Margin = 1.5; // uncovered edge
Layer2X = Layer1X - 2*Layer2Margin;
Layer2Y = Layer1Y - 2*Layer2Margin;
Layer2Z = 3*ThreadZ;
MountX = 46.3 + HoleWindage; // handlebar mounting bracket end plate
MountHoleSpace = 13.0; // end to hole center
MountY = 16.3 + HoleWindage;
MountZ = 4*ThreadZ; // recess depth
MountCap = 3.0; // endcap arc height
MountR = (pow(MountCap,2) + 0.25*pow(MountY,2)) / (2*MountCap); // ... radius
Layer3Margin = 1.5;
Layer3X = Layer2X - 2*Layer3Margin;
Layer3Y = max((Layer2Y - 2*Layer3Margin),(MountY + 8*ThreadWidth));
Layer3Z = 3*ThreadZ;
PlateZ = Layer1Z + Layer2Z + Layer3Z;
// Convenience settings
BuildOffset = 3.0 + Layer1Y/2; // build Y spacing between top & bottom plates
Protrusion = 0.1; // extend holes beyond surfaces for visibility
//---------------
// Create plate with selectable holes
module Plate(hs) {
difference() {
union() {
translate([0,0,Layer1Z/2])
roundedBox([Layer1X,Layer1Y,Layer1Z],CornerR,true);
translate([0,0,Layer1Z + Layer2Z/2])
roundedBox([Layer2X,Layer2Y,Layer2Z],CornerR,true);
translate([0,0,Layer1Z + Layer2Z + Layer3Z/2])
roundedBox([Layer3X,Layer3Y,Layer3Z],CornerR,true);
}
if (0 != hs[0]) {
translate([-HoleSpace,0,PlateZ/2])
cylinder(r=(HoleDia + HoleWindage)/2,
h=(PlateZ + 2*Protrusion),
center=true,$fn=10);
}
if (0 != hs[1]) {
translate([0,0,PlateZ/2])
cylinder(r=(HoleDia + HoleWindage)/2,
h=(PlateZ + 2*Protrusion),
center=true,$fn=10);
}
if (0 != hs[2]) {
translate([HoleSpace,0,PlateZ/2])
cylinder(r=(HoleDia + HoleWindage)/2,
h=(PlateZ + 2*Protrusion),
center=true,$fn=10);
}
}
}
//---------------
//-- Build the things...
translate([0,BuildOffset,0]) Plate(HolesTop);
translate([0,-BuildOffset,0])
difference() {
Plate(HolesBottom);
translate([-(HoleSpace + MountHoleSpace - MountX/2),0,PlateZ - MountZ/2 + Protrusion/2])
intersection() {
cube([MountX,MountY,(MountZ + Protrusion)],center=true);
union() {
cube([(MountX - 2*MountCap),MountY,(MountZ + Protrusion)],center=true);
translate([ (MountX/2 - MountR),0,0])
cylinder(r=MountR,h=(MountZ + Protrusion),center=true);
translate([-(MountX/2 - MountR),0,0])
cylinder(r=MountR,h=(MountZ + Protrusion),center=true);
}
}
}
I loves me my Thing-O-Matic, despite its annoyances…
[Update: Stepper extruder parameters and a tweak to make the mount plate track the hole position correctly.]
I had to drive the old brakes off the mounting studs with a drift punch; the studs were pretty well rusted after a decade of continuous use under the hostile conditions that pass for normal around here. Shined them up, applied a generous layer of Never-Seez, and bolted the new brakes in place.
Turns out that the rear brakes on a Tour Easy are backwards from their orientation on an upright bike: the studs point spinward, so the cable exits on the right side of the frame. Doesn’t make any difference, as that’s how the front brake studs work, but if you’re thinking of buying some fancy brake with odd mounting requirements, you probably shouldn’t.
The installation specs require “more than 39 mm” of cable between the clamp bolt and the bracket on the other arm. The Tour Easy frame tubes are closer together than that, allowing a bare 25 mm of cable.
Rear brake cable and boot
I trimmed the boot to fit, but the real problem is that the arms aren’t at quite the right angle with respect to the braking surface on the rim and provide a bit less leverage than you’d like; the pad alignment is also trickier. I tried adding spacers to the brake pads, but the mounting studs aren’t quite long enough for that.
The first road test indicates the new brakes work much better than the old ones…
Of course, it broke at the first pedal stroke while pushing off across an intersection, which is why I never try to ace out oncoming cars.
This was, mercifully, on the left side of the bike, so I could replace it without removing the rear wheel. Being that sort of bear, I now carry spare screws and we were back on the road in about ten minutes.
A closer look at the head end of the screw shows some interesting details:
Fractured screw – head
The tail end has matching cracks:
Fractured screw – tail
Notice how the cracks are all oriented in the same direction. The screw fractured at the edge of the brazed-on frame fitting, so I suspect the seat stay clamp must be moving just enough to flex the screw across that plane.
I mooched a pair of hardened socket head cap screws from Eks, ground down the head of the right-side screw for better chain clearance around the sprockets, buttered ’em up with Never-Seez, and we’ll see how long Real Steel lasts.
Right-side screw with ground-down head
I really should conjure up a clamp that mounts to the frame tubing, rather than depend on that puny brazed-on fitting, shouldn’t I?
It appears that new Tour Easy ‘bents come with more brazed-on fittings and a more secure seat stay mounting bracket. A photo was there when I looked.
Just got two eyeglasses from a different supplier halfway around the planet, with satisfactory results.
The frames have the largest lenses I could find that weren’t totally dorky; I still want slightly taller lenses, but that’s not the style these days. Their 35 mm lenses are slightly larger than the 35 mm lenses from previous vendor, but IMHO still not quite tall enough for progressive bifocals. The closeup curves seem to start lower on the lens, which is fine.
The 20 mm nose bridge is a Good Thing and made the nosepiece adjustments much easier than before.
Metal Eyeglasses-Vincent
Dimensions
Width 137 mm
Earpiece 144 mm
Lens width 50 mm
Lens height 35 mm
Nose bridge 20 mm
I used a 60 mm Near Pupillary Distance (for the bifocal lens area), which worked fine, although 1 mm might be better.
The regular glasses have the usual options and work fine. The 1.6 “super thin” refractive index (vs 1.5 “regular” in the sunglasses) makes the lenses noticeably thinner than the sunglasses, but I’m not sure it’s worth the upcharge.
- I use my Glasses for: Progressive - Bifocal without a line
- Lens upgrades 5: Progressive Lens (no line)
- Right Sphere(SPH): -3.50
- Right Cylinder (CYL): +0.50
- Right Axis: 180
- Right Addition (near) ADD: +2.25
- Left Sphere(SPH): -3.50
- Left Cylinder (CYL): +0.75
- Left Axis: 155
- Left Addition (near) ADD: +2.25
- Pupillary Distance (PD): 62
- Near PD: 60
- Lens upgrades 3: Super Thin (1.6)
- Eye Protection and Eyeglasses 1: Anti-Scratch
- Eye Protection and Eyeglasses 2: Anti-Reflective
- Eye Protection and Eyeglasses 3: UV Coating
For the sunglasses I tried Old School with-a-line bifocals and, frankly, don’t like them much at all. The line is very distracting in sunlight, which is where I wear sunglasses. Good news: the line falls directly across the fairing on my bike, so I can see the “dashboard” on the handlebars quite clearly. Bad news: the correction is a bit much for the automobile dashboard and, unlike the no-line bifocals, I can’t tune for best picture by nodding my head.
Their 80% gray tint is significantly lighter than the previous vendor’s 80%; next time go for 90%. Good news: unlike the previous vendor, these folks have no trouble with AR/UV coatings over a tint.
- I use my Glasses for: Bifocal - Both distance and reading with a line
- Lens upgrades 4: Bifocal Lens (with line)
- Division of lenses: 70% Distance - 30% Reading
- Right Sphere(SPH): -3.50
- Right Cylinder (CYL): +0.50
- Right Axis: 180
- Right Addition (near) ADD: +2.25
- Left Sphere(SPH): -3.50
- Left Cylinder (CYL): +0.75
- Left Axis: 155
- Left Addition (near) ADD: +2.25
- Pupillary Distance (PD): 62
- Near PD: 60
- Lens upgrades 1: Standard (1.5)
- Eye Protection and Eyeglasses 1: Anti-Scratch
- Eye Protection and Eyeglasses 2: Anti-Reflective
- Eye Protection and Eyeglasses 3: UV Coating
- Tint Key: Grey 80%
- Eye Protection and Eyeglasses 4: Color Tint
The Smell of Molten Projects in the Morning
