  • Hard Drive Platter Mood Light: 3D Printed Structure

    Harvesting a stack of hard drive platters and discovering that four Neopixel strips could stand vertically inside the central hole suggested this overall structure:

    Hard Drive Mood Light - solid model - Show view
    Hard Drive Mood Light – solid model – Show view

    The model includes a parameter for the number of strips, but not everything respects that. I’m not sure I’ll ever make a three-LED column and five strips won’t fit, so it probably doesn’t matter.

    The central pillar holds everything together:

    Hard Drive Mood Light - solid model - Pillar
    Hard Drive Mood Light – solid model – Pillar

    The Neopixel strips slide into those slots, which turned out to be too small to actually print, because the molten plastic pretty much squeezed the slots closed. Some deft pull saw action enlarged them enough to pass the strips, at the cost of tedious hand-fitting and considerable hidden ugliness. Printing the slots slightly larger bangs against the (lack of) printer resolution, because there’s not much wiggle room between the tiny slots and the outer diameter of the column:

    Hard Drive Mood Light - Pillar - Slic3r preview
    Hard Drive Mood Light – Pillar – Slic3r preview

    The three alignment pin holes along each edge sit 6.944 mm on center, which is what you get when you divide the nominal 1 meter strip length by 144 Neopixels. I’m using knockoff Neopixels from halfway around the planet, but they’re probably pretty close to the real thing (also from halfway around the planet, I’m sure).

    All those parts laid out on the platform, along with a fourth set of spacers in case I drop one:

    Hard Drive Mood Light - solid model - Build view
    Hard Drive Mood Light – solid model – Build view

    And they print in cyan PETG just like you’d expect:

    Hard Drive Mood Light - parts on platform
    Hard Drive Mood Light – parts on platform

    The round base (on the right) prints bottom-side-up, with bridging from the rim to the central pillar, and came out looking just fine. The top doesn’t have the central post and the pillar doesn’t have the top recess shown in the model: those tweaks will appear in the next iteration.

    Each tiny triangular spacer gets an alignment pin glued into its inner surface, then four of them get glued to the pillar. This crash test dummy pillar worked out the dimensions, so it’s squat and ugly:

    Hard Drive Platter Mood Light - pillar gluing
    Hard Drive Platter Mood Light – pillar gluing

    It’s clamped to a glass plate (smooth side up!) to force the spacers onto on a plane, with the other clamps smashing them against the pillar. All the other spacers get glued in situ atop each platter as it’s installed, which is a definite downside.

    Installing the Neopixels before assembling the platters seemed to be the right way to go:

    Hard Drive Mood Light - first platter assembly
    Hard Drive Mood Light – first platter assembly

    After that, just stack ’em up:

    Hard Drive Mood Light - top Neopixels
    Hard Drive Mood Light – top Neopixels

    I dry-assembled the upper two spacer sets, so I could pull it apart in case that seemed necessary. Turned out to be a good idea.

    And then screw the lid on top to see what it looks like:

    Hard Drive Mood Light - trial assembly
    Hard Drive Mood Light – trial assembly

    That top screw should be a pan-head or something similarly smooth, rather than a random PC case screw. The sacrificial hard drives provided a bunch of Torx screws that would surely look better; most are far too small.

    I thought a taller stack would be appropriate, but I kinda like the short, squat aspect ratio.

    Now for some wiring…

    The OpenSCAD source code:

    // Hard Drive Platter Mood Light
    // Ed Nisley KE4ZNU November 2015

    Layout = "Show";					// Build Show Pixel LEDString Platters Pillar Spacers TopCap Base

    ShowDisks = 2;						// number of disks in Show layout

    //- Extrusion parameters must match reality!

    ThreadThick = 0.20;
    ThreadWidth = 0.40;

    HoleWindage = 0.2;

    Protrusion = 0.1;			// make holes end cleanly

    inch = 25.4;

    function IntegerMultiple(Size,Unit) = Unit * ceil(Size / Unit);

    //----------------------
    // Dimensions

    ID = 0;
    OD = 1;
    LENGTH = 2;

    Platter = [25.0,95.0,1.27];						// hard drive platters

    LEDStringCount = 3;								// number of LEDs on each strip (Show mode looks odd for less than 3)
    LEDStripCount = 4;								// number of strips (verify locating pin holes & suchlike)

    WireSpace = 1.0;								// allowance for wiring along strip ends

    BaseSize = [40,14,3.0];							// overall base plate outside engine controller slot

    Pixel = [13.0, 1000 / 144, 0.5];				// smallest indivisible unit of LED strip
    PixelMargin = [1.0, 1.0, 2.0];					// LED and circuitry atop the strip

    BeamAngle = 120;								// LED viewing angle
    BeamShape = [
    	[0,0],
    	[Platter[OD]*cos(BeamAngle/2),-Platter[OD]*sin(BeamAngle/2)],
    	[Platter[OD]*cos(BeamAngle/2), Platter[OD]*sin(BeamAngle/2)]
    ];

    PillarSides = 12*4;

    PillarCore = Platter[ID] - 2*(Pixel[2] + PixelMargin[2] + 2.0);		// LED channel distance across pillar centerline
    PillarLength = LEDStringCount*Pixel[1] + Platter[LENGTH];
    echo(str("Pillar core size: ",PillarCore));
    echo(str("      ... length:"),PillarLength);

    Cap = [Platter[ID] + 4.0,Platter[ID] + 4.0 + 10*2*ThreadWidth,2*WireSpace + 6*ThreadThick];		// cap over top of pillar
    CapSides = 16;

    Base = [Platter[ID] + 10.0,0.5*Platter[OD],8.0];
    BaseSides = 16;

    Screw = [2.0,3.0,20.0];							// screws used to secure cap & pillar

    Spacer = [Platter[ID],(Platter[ID] + 2*8),(Pixel[1] - Platter[LENGTH])];
    echo(str("Spacer  OD: ",Spacer[OD]));
    echo(str(" ... thick:",Spacer[LENGTH]));

    LEDStripProfile = [
    	[0,0],
    	[Pixel[0]/2,0],
    	[Pixel[0]/2,Pixel[2]],
    	[(Pixel[0]/2 - PixelMargin[0]),Pixel[2]],
    	[(Pixel[0]/2 - PixelMargin[0]),(Pixel[2] + PixelMargin[2])],
    	[-(Pixel[0]/2 - PixelMargin[0]),(Pixel[2] + PixelMargin[2])],
    	[-(Pixel[0]/2 - PixelMargin[0]),Pixel[2]],
    	[-Pixel[0]/2,Pixel[2]],
    	[-Pixel[0]/2,0]
    ];

    //----------------------
    // Useful routines

    module PolyCyl(Dia,Height,ForceSides=0) {			// based on nophead's polyholes

      Sides = (ForceSides != 0) ? ForceSides : (ceil(Dia) + 2);

      FixDia = Dia / cos(180/Sides);

      cylinder(r=(FixDia + HoleWindage)/2,
    		h=Height,
    	$fn=Sides);
    }

    //- Locating pin hole with glue recess
    //  Default length is two pin diameters on each side of the split

    PinOD = 1.70;

    module LocatingPin(Dia=PinOD,Len=0.0) {

    	PinLen = (Len != 0.0) ? Len : (4*Dia);

    	translate([0,0,-ThreadThick])
    		PolyCyl((Dia + 2*ThreadWidth),2*ThreadThick,4);

    	translate([0,0,-2*ThreadThick])
    		PolyCyl((Dia + 1*ThreadWidth),4*ThreadThick,4);

    	translate([0,0,-(PinLen/2 + ThreadThick)])
    		PolyCyl(Dia,(PinLen + 2*ThreadThick),4);

    }
    //----------------------
    // Pieces

    //-- LED strips

    module OnePixel() {

    	render()
    		rotate([-90,0,0]) rotate(180)				// align result the way you'd expect from the dimensions
    			difference() {
    				linear_extrude(height=Pixel[1],convexity=3)
    					polygon(points=LEDStripProfile);
    				translate([-Pixel[0]/2,Pixel[2],-PixelMargin[0]])
    					cube([Pixel[0],2*PixelMargin[2],2*PixelMargin[0]]);
    				translate([-Pixel[0]/2,Pixel[2],Pixel[1]-PixelMargin[0]])
    					cube([Pixel[0],2*PixelMargin[2],2*PixelMargin[0]]);
    			}
    }

    module LEDString(n = LEDStringCount) {

    	for (i=[0:n-1])
    		translate([0,i*Pixel[1]])
    //			resize([0,Pixel[1] + 2*Protrusion,0])
    				OnePixel();
    }

    //-- Stack of hard drive platters

    module Platters(n = LEDStringCount + 1) {

    	color("gold",0.4)
    	for (i=[0:n-1]) {
    		translate([0,0,i*Pixel[1]])
    			difference() {
    				cylinder(d=Platter[OD],h=Platter[LENGTH],center=false,$fn=PillarSides);
    				cylinder(d=Platter[ID],h=3*Platter[LENGTH],center=true,$fn=PillarSides);
    			}
    	}
    }

    //-- Pillar holding the LED strips

    module Pillar() {

    	difflen = PillarLength + 2*Protrusion;

    //	render(convexity=5)
    	difference() {
    		linear_extrude(height=PillarLength,convexity=4)
    			difference() {
    				rotate(180/(12*4))
    					circle(d=Platter[ID] - 1*ThreadWidth,$fn=PillarSides);

    				for (i=[0:LEDStripCount-1]) 					// clearance for LED beamwidth, may not actually cut surface
    					rotate(i*360/LEDStripCount)
    						translate([PillarCore/2,0,0])
    							polygon(points=BeamShape);

    				for (i=[0:LEDStripCount-1])						// LED front clearance
    					rotate(i*360/LEDStripCount)
    						translate([(PillarCore/2 + Pixel[2]),(Pixel[0] - 2*PixelMargin[0])/2])
    							rotate(-90)
    								square([Pixel[0] - 2*PixelMargin[0],Platter[ID]]);

    			}

    		for (i=[0:LEDStripCount-1])								// LED strip slots
    			rotate(i*360/LEDStripCount)
    				translate([PillarCore/2,0,-Protrusion])
    					linear_extrude(height=difflen,convexity=2)
    						rotate(-90)
    							polygon(points=LEDStripProfile);

    		for (i=[0,90])											// wiring recess on top surface
    			rotate(i)
    				translate([0,0,(PillarLength - (WireSpace/2 - Protrusion))])
    					cube([(PillarCore + 2*Protrusion),Pixel[0] - 2*PixelMargin[0],WireSpace],center=true);

    		for (i=[0:LEDStripCount-1])								// wiring recess on bottom surface
    			rotate(i*90)
    				translate([PillarCore/2 - (WireSpace - Protrusion)/2,0,WireSpace/2 - Protrusion])
    					cube([WireSpace + Protrusion,Pixel[0] - 2*PixelMargin[0],WireSpace],center=true);

    		for (j=[0:LEDStringCount-1])							// platter spacer alignment pins
    			for (i=[0:LEDStripCount-1])
    				rotate(i*360/LEDStripCount + 180/LEDStripCount)
    					translate([(Platter[ID] - 1*ThreadWidth)/2,0,(j*Pixel[1] + Pixel[1]/2 + Platter[LENGTH]/2)])
    						rotate([0,90,0])
    							rotate(45)
    								LocatingPin();

    		translate([0,0,-Protrusion])							// central screw hole
    			rotate(180/4)
    				PolyCyl(Screw[ID],difflen,4);

    		if (false)
    		for (i=[-1,1])											// vertical wire channels
    			rotate(i*360/LEDStripCount + 180/LEDStripCount)
    				translate([PillarCore/2 - 2.0,0,-Protrusion])
    					PolyCyl(2.0,difflen,4);

    		for (i=[-1,1])											// locating pins
    			rotate(i*360/LEDStripCount - 180/LEDStripCount)
    				translate([PillarCore/2 - 2.0,0,0])
    					LocatingPin();
    	}
    }

    //-- Spacers to separate platters

    module Spacers() {

    	difference() {
    		linear_extrude(height=Spacer[LENGTH],convexity=4)
    			difference() {
    				rotate(180/PillarSides)
    					circle(d=Spacer[OD],$fn=PillarSides);

    				for (i=[0:LEDStripCount-1]) 					// clearance for LED beamwidth, may not actually cut surface
    					rotate(i*360/LEDStripCount)
    						translate([PillarCore/2,0,0])
    							polygon(points=BeamShape);

    				for (i=[0:LEDStripCount-1])						// LED front clearance
    					rotate(i*360/LEDStripCount)
    						translate([(PillarCore/2 + Pixel[2]),(Pixel[0] - 2*PixelMargin[0])/2])
    							rotate(-90)
    								square([Pixel[0] - 2*PixelMargin[0],Platter[ID]]);


    				rotate(180/PillarSides)
    					circle(d=Spacer[ID],$fn=PillarSides);		// central pillar fits in the hole
    			}

    		for (i=[0:LEDStripCount-1])
    			rotate(i*360/LEDStripCount + 180/LEDStripCount)
    				translate([Platter[ID]/2,0,(Pixel[1] - Platter[LENGTH])/2])
    					rotate([0,90,0])
    						rotate(45)
    							LocatingPin();

    	}
    }

    //-- Cap over top of pillar

    module TopCap() {

    	difference() {
    		cylinder(d1=(Cap[OD] + Cap[ID])/2,d2=Cap[OD],h=Cap[LENGTH],$fn=CapSides);		// outer lid

    		translate([0,0,-Protrusion])
    			PolyCyl(Screw[ID],Cap[LENGTH] + WireSpace + Protrusion,4);					// screw hole

    		translate([0,0,Cap[LENGTH] - 2*WireSpace])
    			difference() {
    				cylinder(d=Cap[ID],h=2*Cap[LENGTH],$fn=CapSides);						// cutout
    				cylinder(d=2*Screw[OD],h=Cap[LENGTH],$fn=CapSides);						// boss
    			}

    		translate([0,0,Cap[LENGTH] - ThreadThick])
    			cylinder(d=Cap[ID]/2,h=ThreadThick + Protrusion,$fn=CapSides);				// recess boss
    	}
    }

    //-- Base below pillar

    module Base() {

    	SideWidth = 0.5*Base[OD]*sin(180/BaseSides);						// close enough

    	difference() {
    		union() {
    			difference() {
    				cylinder(d=Base[OD],h=Base[LENGTH],$fn=BaseSides);			// outer base

    				translate([0,0,6*ThreadThick])								// main cutout
    					cylinder(d=Base[ID],h=Base[LENGTH],$fn=BaseSides);

    				translate([-SideWidth/2,0,6*ThreadThick]) 					// cable port
    					cube([SideWidth,Base[OD],Base[LENGTH]]);
    			}

    			translate([0,0,Base[LENGTH]/2])									// pillar support is recessed below rim
    				cube([PillarCore,PillarCore,Base[LENGTH] - ThreadThick],center=true);
    		}

    		for (i=[0:LEDStripCount-1])											// wiring recesses
    			rotate(i*90)
    				translate([PillarCore/2 - (WireSpace - Protrusion)/2,0,Base[LENGTH] - WireSpace/2])
    					cube([WireSpace + Protrusion,PillarCore - 4*WireSpace,WireSpace],center=true);

    		translate([0,0,-Protrusion])
    			PolyCyl(Screw[ID],2*Base[LENGTH],4);						// screw hole

    		translate([0,0,-Protrusion])									// screw head recess
    			PolyCyl(8.5,5.0 + Protrusion,$fn=6);

    		for (i=[-1,1])													// locating pins
    			rotate(i*360/LEDStripCount - 180/LEDStripCount)
    				translate([PillarCore/2 - 2.0,0,Base[LENGTH] - ThreadThick])
    					LocatingPin();

    	}

    }

    //----------------------
    // Build it

    if (Layout == "Pixel")
    	OnePixel();

    if (Layout == "LEDString")
    	LEDString(LEDStringCount);

    if (Layout == "Platters")
    	Platters(LEDStringCount + 1);

    if (Layout == "Pillar")
    	Pillar(LEDStringCount);

    if (Layout == "TopCap")
    	TopCap();

    if (Layout == "Base")
    	Base();

    if (Layout == "Spacers")
    	Spacers();

    if (Layout == "Show") {
    	Pillar();

    	for (i=[0:LEDStripCount-1])											// LED strips
    		rotate(i*360/LEDStripCount)
    			translate([PillarCore/2,0,Platter[LENGTH]/2])
    				rotate([90,0,90])
    					color("lightblue") LEDString();
    	if (true)
    	for (j=[0:max(1,ShowDisks - 2)])									// spacers
    		translate([0,0,(j*Pixel[1] + Platter[LENGTH])])
    			color("cyan") Spacers();

    	for (j=[0:max(2,ShowDisks - 2)])										// spacer alignment pins
    		for (i=[0:LEDStripCount-1])
    			rotate(i*360/LEDStripCount + 180/LEDStripCount)
    				translate([(Platter[ID] - 1*ThreadWidth)/2,0,(j*Pixel[1] + Pixel[1]/2 + Platter[LENGTH]/2)])
    					rotate([0,90,0])
    						rotate(45)
    							 color("Yellow",0.25) LocatingPin(Len=4);
    	translate([0,0,PillarLength + 3*Cap[LENGTH]])
    		rotate([180,0,0])
    			TopCap();

    	translate([0,0,-3*Base[LENGTH]])
    		Base();

    	if (ShowDisks > 0)
    		Platters(ShowDisks);

    }

    // Ad-hoc build layout

    if (Layout == "Build") {
    	Pillar();

    	translate([0,Cap[OD],0])
    		TopCap();

    	translate([0,-Base[OD],Base[LENGTH]])
    		rotate([0,180,0])
    			Base();

    	Ybase = Spacer[OD] * (LEDStringCount%2 ? (LEDStringCount - 1) : (LEDStringCount - 2)) / 4;
    	for (i=[0:LEDStringCount])										// build one extra set of spacers!
    		translate([(i%2 ? 1 : -1)*(Spacer[OD] + Base[OD])/2,		// alternate X sides to shrink Y space
    				   (i%2 ? i-1 : i)*Spacer[OD]/2 - Ybase,			// same Y for even-odd pairs in X
    				   0])
    			Spacers();
    }


    The original doodles showing this might work, along with some ideas that wouldn’t:

    Hard Drive Mood Light - Doodles 1
    Hard Drive Mood Light – Doodles 1
    Hard Drive Mood Light - Doodles 2
    Hard Drive Mood Light – Doodles 2
    Hard Drive Mood Light - Doodles 3
    Hard Drive Mood Light – Doodles 3
  • Neopixel Current

    Adafruit’s Neopixels are RGB LEDs with a built-in current-limiting 400 Hz PWM controller and a serial data link. Successive Neopixels aren’t synchronized, so their PWM cycles can produce serious current spikes.

    Lighting up just the red LED in two Neopixels at PWM 16/255 produces this current waveform (at 10 mA/div):

    Neopixel current 10 mA - 16-0-0 0-1
    Neopixel current 10 mA – 16-0-0 0-1

    Each red LED draws about 20 mA, so when the two Neopixel PWM cycles coincide, you get a nasty 40 mA spike. When they don’t coincide, you get a pair of 20 mA pulses. Those pulses walk with respect to each other at a pretty good clip; the oscillators aren’t trimmed to precision.

    Lighting up three Neopixels with PWM 16/255 on the red does exactly what you’d expect. The horizontal scale  is now 100 µs/div, making the PWM pulses five times wider:

    Neopixel current 10 mA - 16-0-0 0-1-2
    Neopixel current 10 mA – 16-0-0 0-1-2

    The narrow spike comes from the brief shining instant when all three Neopixels were on at the same time. Now you have three PWM pulses, each with slightly different periods.

    Remember that these are PWM 16/255 pulses. When they’re at full brightness, PWM 255/255, there’s only a brief downtime between pulses that last nearly 2.5 ms and they’ll overlap like crazy.

    Obviously, the more Neopixels and the lower the average PWM setting, the more the average current will tend toward the, uh, average. However, it will have brutal spikes, so the correct way to size the power supply is to multiply the number of Neopixels in the string by the maximum possible 60 mA/Neopixel… which gets really big, really fast.

    A 1 meter strip of 144 knockoff Neopixels from the usual eBay supplier will draw 144 x 60 mA = 8.6 A when all the pulses coincide. Worse, the supply must be able to cope with full-scale transients and all the fractions in between. A husky filter cap would be your friend, but you need one with a low ESR and very high capacity to support the transients.

    No wonder people have trouble with their Neopixel strings; you really shouldn’t (try to) run more than one or two directly from an Arduino’s on-board regulator…

  • Ed’s Fireball Hot Cocoa Recipe

    The hot chocolate recipe on the back of the cocoa container tastes like bland liquid candy.

    This tastes the way hot cocoa should:

    Ingredients

    • 1 generous cup milk (full-fat is where it’s at)
    • 1 tbsp white sugar (just do it)
    • 3 tbsp cocoa powder (not chocolate drink mix)
    • 1/4 tsp Vietnamese cinnamon
    • 1 tbsp milk for mixing
    • few drops peppermint extract
    • 1/4 tsp vanilla extract
    • 20 oz Starbucks City Mug (got ’em cheap at a tag sale)

    Preparation

    • Microwave the generous cup o’ milk for 1 minute
    • Mix dry ingredients in the giant mug
    • Stir in just enough cold milk to make a thick mud (*)
    • Add peppermint drops using 1/4 tsp measure
    • Rinse 1/4 tsp measure with vanilla
    • Blend the extracts into the mud (*)
    • Stir in warm milk, scraping mud off the mug
    • Microwave for another 45 s or so
    • Stir to blend

    What’s going on:

    • More cocoa = more flavor, pure & simple
    • Less sugar = more cocoa bite
    • Vietnamese cinnamon adds the aroma & zip of those old Atomic Fireballs
    • Vanilla smooths the taste
    • Peppermint reminds you it’s winter

    Sipping a cup in the afternoon banishes the urge to power-nosh anything else until suppertime…

    * Update: non-alkalized / non-Dutch-process cocoa doesn’t blend well. Mix up the mud, let it set for 15 minutes, blend again, pause for 5 minutes, then proceed. Wonderfully smooth with no powder bombs.

  • White LED Failures

    Well, that didn’t take long:

    Ring Light Mount - failed LEDs
    Ring Light Mount – failed LEDs

    The two dim LEDs to the left are actually very faintly lit, so I think the dark one has failed nearly open.

    When I installed those nine central LEDs, I didn’t notice that the bag (from the usual eBay source, IIRC) contained two different types of white LEDs. The difference shows up clearly under UV that lights up the yellow phosphor:

    Ring Light Mount - failed LEDs in UV
    Ring Light Mount – failed LEDs in UV

    By random chance, each of the three groups has one non-fluorescing LED. If I can extricate them from their epoxy tomb, maybe I can figure out which one failed.

    Rather than replace those, I’ll try a new-fangled chip-on-board light source, even though that might require a current limiter and maybe a heatsink. Obviously, this is getting out of hand, but maybe the same folks who can’t make a white LED can make a functional COB assembly for a buck… [sigh]

  • Monthly Image: Fireworks Moonwalk

    The Poughkeepsie Bridge always looks good in its necklace lights:

    Fireworks Moonwalk - Poughkeepsie Bridge
    Fireworks Moonwalk – Poughkeepsie Bridge

    Each catenary carries a string of lights that produces a slight double-exposure effect. It’s not your eyes, there really are two closely spaced lights.

    The moon hadn’t yet risen, so the southern sky got completely dark. That makes for an easy-to-assemble south-facing panorama with Poughkeepsie on the left:

    Walkway Panorama - South View - 2015-10-29
    Walkway Panorama – South View – 2015-10-29

    There’s also a north panorama from a previous moonwalk.

    The fireworks launched from a barge in the middle of the Hudson River to eliminate the hassle of flaming debris falling on bystanders:

    Fireworks Moonwalk - Fireworks
    Fireworks Moonwalk – Fireworks

    A stiff south wind blew the smoke over the Walkway, far to our right; everybody in that section got a good introduction to fireworks chemistry.

    A good time was had by all!

  • Poughkeepsie Day School Mini MakerFaire

    In the (admittedly unlikely) event you’re in the neighborhood today, visit the Poughkeepsie Mini MakerFaire. I’ll be doing a “Practical 3D Printing” show-n-tell in one of the tiny music practice rooms in the main hallway, handing out tchochkes, and generally talking myself hoarse. The HP 7475A plotter will be cranking out Superforumulas next door, too, because everybody loves watching a plotter.

    Usually, I print dump trucks or some such, but yesterday I hammered out the models for two adapters that mate the new vacuum cleaner to some old tools, so I’ll be doing live-fire production printing. I’m sure you can get adapters on Amazon, but what’s the fun in that?

    The magic wand that sucks dust off the evaporator coils under the refrigerator slides into the bottom end of this one:

    Refrigerator Coil Wand Adapter
    Refrigerator Coil Wand Adapter

    And the snout of this slides into the tiny floor brush that fits into spots the new one can’t reach:

    Floor Brush Adapter
    Floor Brush Adapter

    And, with a Faire wind in my sails, perhaps I can run off the bits required for a hard drive mood light:

    Hard Drive Mood Light - solid model - Show view
    Hard Drive Mood Light – solid model – Show view

    More details on all those later…

  • Hard Drive Platter Mood Light: Neopixel Firmware

    Having accumulated a pile of useless hard drives, it seemed reasonable to harvest the platters and turn them into techie mood lights (remember mood lights?). Some doodling showed that four of Adafruit’s high-density Neopixel strips could stand up inside the 25 mm central hole, completely eliminating the need to putz around with PWM drivers and RGB LEDs: one wire from an Arduino Pro Mini and you’re done:

    const byte PIN_NEO = 6;				// DO - data out to first Neopixel


    The firmware creates three sine waves with mutually prime periods, then updates the RGB channels with raised-sine values every 10 ms. The PdBase constant defines the common conversion from milliseconds to radians:

    const float PdBase = 0.05 * TWO_PI / 1000.0;	// scale time in ms to radians


    The leading 0.05 = 1/20 means the sine wave will repeat every 20 s = 20000 ms.

    Dividing that period by three small primes produces an RGB pattern that will repeat every 5x11x17 = 935 PdBase cycles = 18.7×103 s = 5.19 h:

    const float Period[] = {PdBase/5.0,PdBase/11.0,PdBase/17.0};		// mutually prime periods


    That’s languid enough for me, although I admit most of the colors look pretty much the same. Obviously, you can tune for best picture by dinking with a few constants.

    A Phase array sets the starting phase to 3π/2 = -90 degrees:

    float Phase[] = {3.0 * HALF_PI,3.0 * HALF_PI,3.0 * HALF_PI};		// sin(3π/2 ) = -1, so LEDs are off


    Jiggling those starting phases produces a randomized initial color that’s close to dark:

    	MillisNow = MillisThen = millis();
    	randomSeed(MillisNow + analogRead(6) + analogRead(7));
    	printf("Phases: ");
    	for (byte i=0; i<3; i++) {
    		Phase[i] += random(-1000,1000) * HALF_PI / 1000.0;
    		printf("%d ",(int)(Phase[i]*RAD_TO_DEG));
    	}
    	printf(" deg\r\n");


    With all that in hand, converting from time to color goes like this:

    uint32_t SineColor(unsigned long t) {
    byte rgb[3];

    	for (byte i=0; i<3; i++) {
    			rgb[i] = Intensity[i]/2.0 * (1 + sin(t * Period[i] + Phase[i]));
    	}
    	return strip.Color(rgb[0],rgb[1],rgb[2]);
    }


    The rest of the code scales neatly with the strip length defined in the magic instantiation:

    Adafruit_NeoPixel strip = Adafruit_NeoPixel(12, PIN_NEO, NEO_GRB + NEO_KHZ800);


    Although the colors change very slowly, shifting them all one chip toward the end of the 144 Neopixel strip at each update produces a noticeable difference that reassured me this whole mess was working:

    		for (int i=strip.numPixels()-1; i>0; i--) {
    			c = strip.getPixelColor(i-1);
    			strip.setPixelColor(i,c);
    		}

    		c = SineColor(MillisNow);
    		strip.setPixelColor(0,c);
    		strip.show();


    And with that in hand, It Just Worked…

    However, it’s worth noting that each Neopixel draws a bit over 60 mA at full white, which works out to a smidge under 9 A for a 144 LED strip. Because they’re PWM devices, the LEDs are either full-on or full-off, so the peak current can actually be 9 A, regardless of any reduced duty cycle to limit the intensity.

    The Adafruit driver includes an overall intensity control, but I added an Intensity array with separate values for each channel:

    float Intensity[] = {128.0,128.0,128.0};							// pseudo current limit - PWM is always full current


    That would allow throttling back the blue LEDs a bit to adjust the overall color temperature, but that’s definitely in the nature of fine tuning.

    The Adafruit Neopixel guide recommends a honkin’ big cap right at the strip, plus a 470 Ω decoupling resistor at the first chip’s data input. I think those attempt to tamp down the problems caused by underpowered supplies and crappy wiring; running it at half intensity produced a maximum average current just under the supply’s 3 A limit.

    The complete Arduino source code:

    // Neopixel mood lighting for hard drive platter sculpture
    // Ed Nisley - KE4ANU - November 2015

    #include <Adafruit_NeoPixel.h>

    //----------
    // Pin assignments

    const byte PIN_NEO = 6;				// DO - data out to first Neopixel

    const byte PIN_HEARTBEAT = 13;		// DO - Arduino LED

    //----------
    // Constants

    const int UPDATEMS = 10ul - 4ul;		// update LEDs only this many ms apart minus loop() overhead

    const float PdBase = 0.05 * TWO_PI / 1000.0;	// scale time in ms to radians

    const float Period[] = {PdBase/5.0,PdBase/11.0,PdBase/17.0};		// mutually prime periods
    float Phase[] = {3.0 * HALF_PI,3.0 * HALF_PI,3.0 * HALF_PI};		// sin(3π/2 ) = -1, so LEDs are off
    float Intensity[] = {128.0,128.0,128.0};							// pseudo current limit - PWM is always full current

    //----------
    // Globals

    unsigned long MillisNow;
    unsigned long MillisThen;

    Adafruit_NeoPixel strip = Adafruit_NeoPixel(12, PIN_NEO, NEO_GRB + NEO_KHZ800);

    uint32_t FullWhite = strip.Color(255,255,255);
    uint32_t FullOff = strip.Color(0,0,0);

    //--- figure color from time in ms

    uint32_t SineColor(unsigned long t) {
    byte rgb[3];

    	for (byte i=0; i<3; i++) {
    			rgb[i] = Intensity[i]/2.0 * (1 + sin(t * Period[i] + Phase[i]));
    	}
    	return strip.Color(rgb[0],rgb[1],rgb[2]);
    }

    //-- Helper routine for printf()

    int s_putc(char c, FILE *t) {
      Serial.write(c);
    }

    //------------------
    // Set the mood

    void setup() {

    uint32_t c;

    	pinMode(PIN_HEARTBEAT,OUTPUT);
    	digitalWrite(PIN_HEARTBEAT,LOW);	// show we arrived

    	Serial.begin(57600);
    	fdevopen(&s_putc,0);				// set up serial output for printf()

    	printf("Mood Light with Neopixels\r\nEd Nisley - KE4ZNU - November 2015\r\n");

    /// set up Neopixels

    	strip.begin();
    	strip.show();

    // lamp test: run a brilliant white dot along the length of the strip

    	printf("Lamp test: walking white\r\n");

    	strip.setPixelColor(0,FullWhite);
    	strip.show();
    	delay(500);

    	for (int i=1; i<strip.numPixels(); i++) {
    		digitalWrite(PIN_HEARTBEAT,HIGH);
    		strip.setPixelColor(i-1,FullOff);
    		strip.setPixelColor(i,FullWhite);
    		strip.show();
    		digitalWrite(PIN_HEARTBEAT,LOW);
    		delay(500);
    	}

    	MillisNow = MillisThen = millis();
    	randomSeed(MillisNow + analogRead(6) + analogRead(7));
    	printf("Phases: ");
    	for (byte i=0; i<3; i++) {
    		Phase[i] += random(-1000,1000) * HALF_PI / 1000.0;
    		printf("%d ",(int)(Phase[i]*RAD_TO_DEG));
    	}
    	printf(" deg\r\n");

    	c = SineColor(MillisNow);
    	printf("Initial time: %08lx -> color: %08lx\r\n",MillisNow,c);

    	for (int i=0; i<strip.numPixels()-1; i++) {
    		strip.setPixelColor(i,c);
    	}

    	strip.show();

    }

    //------------------
    // Run the mood

    void loop() {

    byte r,g,b;
    uint32_t c;

    	MillisNow = millis();
    	if ((MillisNow - MillisThen) > UPDATEMS) {
    		digitalWrite(PIN_HEARTBEAT,HIGH);

    		for (int i=strip.numPixels()-1; i>0; i--) {
    			c = strip.getPixelColor(i-1);
    			strip.setPixelColor(i,c);
    		}

    		c = SineColor(MillisNow);
    		strip.setPixelColor(0,c);
    		strip.show();

    		MillisThen = MillisNow;
    		digitalWrite(PIN_HEARTBEAT,LOW);
    	}
    }
