A pair of 3D printed smashed glass coasters for a friend:

The black PETG coaster under the French Press:

The white PETG coaster under the mug:

They’re considerably improved from the first attempt:

More details to follow …
The Smell of Molten Projects in the Morning
Ed Nisley's Blog: Shop notes, electronics, firmware, machinery, 3D printing, laser cuttery, and curiosities. Contents: 100% human thinking, 0% AI slop.
They might be Art

A pair of 3D printed smashed glass coasters for a friend:

The black PETG coaster under the French Press:

The white PETG coaster under the mug:

They’re considerably improved from the first attempt:

More details to follow …

After positioning the smashed glass fragments atop reflective metalized paper in the 3D printed coaster base, I poured epoxy over everything and, after popping some bubbles, left it to cure:

I sprayed the white-ish fragments (on the left) with satin-finish clear rattlecan “paint” in the hopes it would keep epoxy out of the cracks between the glass cuboids and leave the highly reflective air gaps. While it did a reasonable job of sealing, it bonded poorly with the epoxy and produced a dull surface finish.
The unsprayed fragments (on the right) turned out better, although the one in the upper right has a thin air bubble / layer on top. The unsealed cracks between the cuboids show well against the reflective layers, so I think spraying the fragments isn’t worth the effort.
The printed base has a 1 mm tall rim to retain the epoxy:

I mixed enough epoxy to fill half the volume of a disk with the same overall OD and depth (V = h × π × d²/4), which turned out to be barely enough produce a level surface at the rim. There didn’t seem that much epoxy left on the various measuring / mixing cups, but next time I’ll round upward.
Many of the bubbles emerged from below the metalized paper, as well as between the glass and paper, so next time:
The top isn’t exactly flat and has some dull areas, so at some point I want to make it flat with 220 grit sandpaper, work up to some 3000 grit paper I’ve been saving for a special occasion, then finish it off with Novus polish. Which seems like enough hassle to keep the coaster under my sippy cup for a while.

The motivation for making Yet Another Coaster was to see if combining a few techniques I’ve recently learned would produce a nicer result.
Spoiler: Yup, with more to be learned and practiced.
This is a somewhat nonlinear narrative reminding me of things to do and not do in the future, so don’t treat it as a direct how-to set of instructions.
Thus far, the best way to highlight fragments of smashed glass has been to put them atop an acrylic mirror:

But a 3 mm acrylic mirror layer makes for a rather thick coaster:

The glass fragments sit inside holes in the next two (or three or whatever) acrylic layers, which must have a total thicknesses slightly more than the glass thickness and remain properly aligned while assembling the whole stack:

Bonus: all that cutting generates an absurd amount of acrylic scrap. I eventually put much of it to good use, but not producing it in the first place would be a Good Thing …
So 3D print the entire base, which requires generating a solid model with recesses for the fragments:

Because there’s no real justification for an optical-quality mirror under smashed glass, use reflective metallized paper in the recesses as reflectors:

The glass is more-or-less greenish-blueish, so I used a strip of green metallized paper that made the glass fragments green. Obviously there’s some room for choice down there.
Both the base and the reflectors use outlines of the fragments, so I started with a scan of the approximate layout in GIMP:

I traced the outline of each fragment using the Scissors Select Tool, which lays line segments along the sharpest gradient between clicked points, then switched into Quick Mask mode to adjust & smooth the results:

That’s the result after sketching & saving all the paths as separate SVG files to allow importing them individually into InkScape, OpenSCAD, and LightBurn.
Which turned out to be suboptimal, as it let me write an off-by-one blooper omitting the last file from the OpenSCAD model:
fn = "Fragment layout - 4in.svg";
fp = ["A","B","C","D","E","F"];
<snippage>
for (p = fp)
import(fn,id=str("Fragment ",p));
A better choice puts all the paths into a single named group, saved as a single SVG file, then importing that group from the file using its name, along these lines:
fn = "Fragment layout - 4in.svg";
fg = ["Fragments"];
<snippage>
import(fn,id=fg);
It’s not clear if I can do that directly from GIMP by saving all the paths in a single file, then importing that lump into Inkscape as a group, but it’ll go something like that.
After getting the fragment paths into Inkscape, add a 0.5 mm offset to each path to clear any non-vertical edges. This will be checked with the template cut using LightBurn as described below.
Add a 1 mm rim around the outside, with the 4 inch OD matching the usual PSA cork base:

Now’s the time to nudge / rotate the outlines so they have at least a millimeter of clearance on all sides / ends, because that’s about as thin a section of printed plastic as you want.
Locating the center of the OD (and, thus, everything inside) at the lower-left corner of the Inkscape page will put them at the OpenSCAD origin. I have set Inkscape to have its origin at the lower left, rather than the default upper left, so your origin may vary.
Select one of the paths:

Then set the ID in its Object Properties:

There is an interaction between the name over in the Layers and Objects window, which apparently comes from the GIMP path name for the imported fragments, and the resulting ID and Label in the Object Properties window. However, renaming an object on the left, as for the Rim and Perimeter circles, does not set their ID or Label on the right. Obviously, I have more learning to do before this goes smoothly.
With everything laid out and named and saved in an SVG file, the OpenSCAD program is straightforward (and now imports all the fragments):
include <BOSL2/std.scad>
NumSides = 4*4*3*4;
fn = "Fragment layout - 4in.svg";
fp = ["A","B","C","D","E","F","G"];
FragmentThick = 5.0;
BaseThick = 1.0;
RimHeight = 1.5;
union() {
linear_extrude(h=BaseThick)
import(fn,id="Perimeter",$fn=NumSides);
linear_extrude(h=BaseThick + FragmentThick + RimHeight)
difference() {
import(fn,id="Perimeter",$fn=NumSides);
import(fn,id="Rim",$fn=NumSides);
}
up(BaseThick - 0.05)
linear_extrude(h=FragmentThick)
difference() {
import(fn,id="Perimeter",$fn=NumSides);
for (p = fp)
import(fn,id=str("Fragment ",p));
}
}
Which squirts out the solid model appearing above.
Feeding it into PrusaSlicer turns the model into something printable:

And after supper I had one in my hands.
Before doing that, however, import the same SVG file into LightBurn, as on the left:

On the right, duplicate it, put the inner Rim on a tool layer, put the rest on a layer set to cut chipboard, and make a template to verify those holes fit around the fragments:

Which a few didn’t, explaining why I go to all that trouble. Iterate through GIMP → paths → SVG → Inkscape → LightBurn until it’s all good. Obviously, you do this before you get too far into OpenSCAD, but they all derive from the Inkscape layout, so there’s not a lot of wasted motion.
The middle LightBurn layout insets the fragment outlines by 0.25 mm to ensure the paper fits easily and puts them on a layer set to cut metallized paper. Those fragments then get duplicated and rearranged within the rectangle on the top to fit a strip of metallized paper from the scrap box. Fire The Laser to cut them out and stick them to the bottom of their corresponding 3D printed recesses with leftover snippets of craft adhesive sheet as shown above.
I had originally intended to cover the bottom of the entire sheet of metallized paper with an adhesive sheet, but realized the whole affair was going to be submerged in epoxy, so just making sure the paper didn’t float away would suffice.
Next, mix up some epoxy …

Having recently had to move the flat box of shattered glass to get something from behind it, I figured I could apply new techniques to old material :

This is something of a test case to restart the whole process, so it has a few bloopers. This post covers the results, with more detail on the process to follow.
Arrange some good-looking shattered glass fragments within the 4 inch circle on the fixture:

Scan it, trace the outlines into paths using GIMP, label the paths in Inkscape, import into LightBurn to laser-cut the chipboard disk in that picture to verify enough clearance around the fragments, import into OpenSCAD, and produce a solid model for PrusaSlicer:

While it’s printing, laser-cut green metallized paper to serve as a reflecting layer below the glass, then affix the paper to the bottom of the recesses:

During that process I discovered one of the fragment recesses didn’t make it from the Inkscape SVG file to the OpenSCAD model:

Like I said: bloopers. That fragment now has its place in the OpenSCAD code and the slicer preview above, not that I have matching fragments to build another one.
Put all but one fragment in their places, pour clear epoxy over everything, pop bubbles for a while, then let it cure overnight:

Stick a PSA cork disk on the bottom and it’s ready for service.
I’ve seen worse … :grin:

Just to see what it’d look like, I tweaked the SVG generator to reduce the size of the square blocks on successive layers:
MatrixEls.append(
svg.Rect(
x=as_mm(SheetCenter[X] - MatrixOA[X]/2 + x + ThisLayer*args.inset),
y=as_mm(SheetCenter[Y] - MatrixOA[Y]/2 + y + ThisLayer*args.inset),
width=as_mm(CellSize[X] - 2*ThisLayer*args.inset),
height=as_mm(CellSize[Y] - 2*ThisLayer*args.inset),
stroke=s,
stroke_width=DefStroke,
fill="none",
)
)
Which looks OK-ish, although not significantly different from the straight-hole versions:

The taper shows off the layer colors along the sides of the holes:

Unfortunately, it also makes the corner blemishes painfully obvious:

My first attempt didn’t skootch the squares over by the size of the inset, thus neatly aligning the upper left corners and giving the bottom right corners twice the inset:

Which made those gnarly corners painfully obvious.
I tried stacking the sheets with their bottom side upward, hoping to disguise the edge charring, but to no avail.
The inset code remains in place with a default of zero:
parser.add_argument('--inset', type=float, default=0.0)
Sometimes the simplest choice is the right one.

Change the physical sizes in the SVG layered paper generator to match 24×18 inch construction paper:
PageSize = (round(24*INCH,3), round(18*INCH,3))
SheetCenter = (PageSize[X]/2,PageSize[Y]/2)
SheetSize = (610,450) # overall sheet
AlignOC = (600,440) # alignment pins in corners
AlignOD = 5.0 # … pin diameter
MatrixOA = (590,430) # outer limit of cell matrix
Tweak the defaults for 59×43 squares:
parser = ArgumentParser()
parser.add_argument('--layernum', type=int, default=0)
parser.add_argument('--colors', type=int, default=8)
parser.add_argument('--seed', type=int, default=1)
parser.add_argument('--width', type=int, default=59)
parser.add_argument('--height', type=int, default=43)
args = parser.parse_args()
Run the program ten times to generate ten SVG images:
for i in {00..09} ; do python Layers\ -\ 24x18.py --layernum=$i --colors=9 > Test_$i.svg ; done
The LightBurn layout dwarfs the machine platform:

Fire The Laser ten times and you get a wall hanging:

That’s a trial alignment atop a cardboard box on the Basement Shop floor, because gluing those 24×18 inch sheets of paper requires time on the Sewing Table, which is currently occupied by a much higher priority project. The brown innermost circle in the design is entirely separate from the brown Amazon cardboard box underneath everything.
Fairly obviously, you’d want something other than brown at the focal point of that design, but following the EIA color code gives me some confidence the result matches the intention. Feel free to tart it up with your own colors.
I laid a 29×23 inch sheet of sketch paper on the honeycomb, distributed neodymium bar magnets around the perimeter, and cut a 24×18 rectangle out of the middle:

Those squares are the cutouts from the brown sheet, minus what you see in the lead picture.
The black rectangle on the left of the LightBurn layout above is the 24×18 inch cut for the fixture. Centering that rectangle on the LightBurn layout (click-select, Ctrl-D to duplicate, then hit P to move it to the center) means aligning each of the ten patterns requires nothing more than the same click-select / dupe / P, with no delicate fiddling.
Then just lay each colored sheet into the hole and it’s properly aligned. Because the machine homes to the same physical location every time it’s turned on and the fixture is mmm fixed to the platform, cutting all ten sheets over the course of two days proceeded smoothly.
Cutting 2537 holes in the black mask takes a little under an hour:

The other sheets have fewer holes and go progressively faster:

The white sheet on the bottom has four alignment holes and four layer ID holes, so the cuts take a few seconds.
That was easy …

Changing the formula generating the matrix values and cleaning up some infelicitous code choices produces a much more pleasing result:

The random squares still look OK, though:

Thresholding the distance from a randomly chosen point creates circular rainbows:
CenterPoint = (choice(range(args.width)),choice(range(args.height)))
CellMatrix = [[math.hypot(x - CenterPoint[X],y - CenterPoint[Y])
for y in range(args.height)]
for x in range(args.width)]
dmax = max(list(chain.from_iterable(CellMatrix)))
LayerThreshold = (ThisLayer/Layers)*dmax
The Python program generates one SVG image file representing a single layer, as determined by the Bash one-liner invoking it:
for i in {00..16} ; do python Layers\ -\ 200mm.py > Test_$i.svg ; done
In real life you’d also use a different random seed for each set of layers, but that’s just another command line optIon.
Import those 17 SVG images into LightBurn, arrange neatly, snap each one to the middle of the workspace grid (and thus the aligned template), then Fire The Laser:

Feeding paper into the laser in rainbow (actually, heavily augmented / infilled EIA color code) order, plus the black mask, produces the aforementioned pleasing result:

Glue the sheets in the assembly fixture:

The white layer is uncut, other than the four alignment holes (with a rivnut poking up) and its binary layer number (16, backwards because upside-down), and appears in only the farthest corners of the rainbow.
Protip: doing the stack upside-down means you smear glue stick on the hidden side of each sheet. If you avoid slobbering glue into the cut square holes, nothing can go wrong.
Making these things produces the happiest chip tray ever:

I swept half a dozen pictures worth of squares into a small box and gave it away to someone with a larger small-child cross-section than mine, whereupon a slight finger fumble turned the contents into a glitter bomb. Sorry ’bout that.
The Python source code as a GitHub Gist:
| # Generator for rainbow block layered paper | |
| # Ed Nisley – KE4ZNU | |
| # 2025-08-03 cargo-culted from svg library examples | |
| import svg | |
| import math | |
| from argparse import ArgumentParser | |
| from random import randint, choice, seed | |
| from itertools import chain | |
| from pprint import pprint | |
| INCH = 25.4 | |
| X = 0 | |
| Y = 1 | |
| def as_mm(number): | |
| return repr(number) + "mm" | |
| parser = ArgumentParser() | |
| parser.add_argument('–layernum', type=int, default=0) | |
| parser.add_argument('–colors', type=int, default=16) | |
| parser.add_argument('–seed', type=int, default=1) | |
| parser.add_argument('–width', type=int, default=16) | |
| parser.add_argument('–height', type=int, default=16) | |
| parser.add_argument('–debug', default=False) | |
| args = parser.parse_args() | |
| PageSize = (round(8.5*INCH,3), round(11.0*INCH,3)) | |
| SheetCenter = (PageSize[X]/2,PageSize[X]/2) # symmetric on Y! | |
| SheetSize = (200,200) # overall sheet | |
| AlignOC = (180,180) # alignment pins in corners | |
| AlignOD = 5.0 # … pin diameter | |
| MatrixOA = (170,170) # outer limit of cell matrix | |
| CellCut = "black" # C00 Black | |
| SheetCut = "red" # C02 Red | |
| HeavyCut = "rgb(255,128,0)" # C05 Orange black mask paper is harder | |
| HeavyCellCut = "rgb(0,0,160)" # C09 Dark Blue ditto | |
| Tooling = "rgb(12,150,217)" # T2 Tool | |
| DefStroke = "0.2mm" | |
| DefFill = "none" | |
| ThisLayer = args.layernum # determines which cells get cut | |
| Layers = args.colors # black mask = 0, color n = not perforated | |
| SashWidth = 1.5 # between adjacent cells | |
| CellSize = ((MatrixOA[X] – (args.width – 1)*SashWidth)/args.width, | |
| (MatrixOA[Y] – (args.height – 1)*SashWidth)/args.height) | |
| CellOC = (CellSize[X] + SashWidth,CellSize[Y] + SashWidth) | |
| if args.seed: | |
| seed(args.seed) | |
| #— accumulate tooling layout | |
| ToolEls = [] | |
| # mark center of sheet for drag-n-drop location | |
| ToolEls.append( | |
| svg.Circle( | |
| cx=SheetCenter[X], | |
| cy=SheetCenter[Y], | |
| r="2mm", | |
| stroke=Tooling, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ) | |
| ) | |
| # mark page perimeter for alignment check | |
| if False: | |
| ToolEls.append( | |
| svg.Rect( | |
| x=0, | |
| y=0, | |
| width=as_mm(PageSize[X]), | |
| height=as_mm(PageSize[Y]), | |
| stroke=Tooling, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ) | |
| ) | |
| # center huge box on matrix center | |
| if False: | |
| ToolEls.append( | |
| svg.Rect( | |
| x=as_mm(SheetCenter[X] – 2*SheetSize[X]/2), | |
| y=as_mm(SheetCenter[Y] – 2*SheetSize[Y]/2), | |
| width=as_mm(2*SheetSize[X]), | |
| height=as_mm(2*SheetSize[Y]), | |
| stroke=Tooling, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ) | |
| ) | |
| #— accumulate sheet cuts | |
| SheetEls = [] | |
| # cut perimeter | |
| SheetEls.append( | |
| svg.Rect( | |
| x=as_mm(SheetCenter[X] – SheetSize[X]/2), | |
| y=as_mm(SheetCenter[Y] – SheetSize[Y]/2), | |
| width=as_mm(SheetSize[X]), | |
| height=as_mm(SheetSize[Y]), | |
| stroke=SheetCut if ThisLayer > 0 else HeavyCut, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ), | |
| ) | |
| # cut layer ID holes except on mask layer | |
| if ThisLayer > 0: | |
| c = ((1,1)) | |
| h = f'{ThisLayer:0{Layers.bit_length()}b}' | |
| for i in range(Layers.bit_length()): | |
| SheetEls.append( | |
| svg.Circle( | |
| cx=as_mm(SheetCenter[X] + c[X]*AlignOC[X]/2 – (i + 2)*AlignOD), | |
| cy=as_mm(SheetCenter[Y] + c[Y]*AlignOC[Y]/2), | |
| r=AlignOD/4 if h[-(i + 1)] == '1' else AlignOD/8, | |
| stroke=SheetCut, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ) | |
| ) | |
| # cut alignment pin holes except on mask layer | |
| if ThisLayer > 0: | |
| for c in ((1,1),(-1,1),(-1,-1),(1,-1)): | |
| SheetEls.append( | |
| svg.Circle( | |
| cx=as_mm(SheetCenter[X] + c[X]*AlignOC[X]/2), | |
| cy=as_mm(SheetCenter[Y] + c[Y]*AlignOC[Y]/2), | |
| r=as_mm(AlignOD/2), | |
| stroke=SheetCut, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ) | |
| ) | |
| #— calculate matrix contents | |
| CenterPoint = (choice(range(args.width)),choice(range(args.height))) | |
| CellMatrix = [[math.hypot(x – CenterPoint[X],y – CenterPoint[Y]) | |
| for y in range(args.height)] | |
| for x in range(args.width)] | |
| dmax = max(list(chain.from_iterable(CellMatrix))) | |
| if args.debug: | |
| print(CenterPoint) | |
| print(dmax) | |
| pprint(CellMatrix) | |
| print() | |
| #— accumulate matrix cuts | |
| LayerThreshold = (ThisLayer/Layers)*dmax | |
| if args.debug: | |
| print(LayerThreshold) | |
| MatrixEls = [] | |
| for i in range(args.width): | |
| x =i*CellOC[X] | |
| for j in range(args.height): | |
| y = j*CellOC[Y] | |
| if args.debug: | |
| print(i) | |
| print(j) | |
| print(CellMatrix[i][j]) | |
| if ThisLayer == 0: # black mask | |
| s = HeavyCellCut | |
| elif LayerThreshold < CellMatrix[i][j]: # rest of sheets above color layer | |
| s = CellCut | |
| else: | |
| s = Tooling # at or below color layer | |
| MatrixEls.append( | |
| svg.Rect( | |
| x=as_mm(SheetCenter[X] – MatrixOA[X]/2 + x), | |
| y=as_mm(SheetCenter[Y] – MatrixOA[Y]/2 + y), | |
| width=as_mm(CellSize[X]), | |
| height=as_mm(CellSize[Y]), | |
| stroke=s, | |
| stroke_width=DefStroke, | |
| fill="none", | |
| ) | |
| ) | |
| #— assemble and blurt out the SVG file | |
| if not args.debug: | |
| canvas = svg.SVG( | |
| width=as_mm(PageSize[X]), | |
| height=as_mm(PageSize[Y]), | |
| elements=[ | |
| ToolEls, | |
| SheetEls, | |
| MatrixEls | |
| ], | |
| ) | |
| print(canvas) |
